Panasonic CS-A24BB4P Service Manual

NO. PART DESCRIPTION QTY. CU-A34BBP5 CU-A34BBP8 CU-A43BBP8 CU-A50BBP8
1 BASE PAN ASS’Y 1 CWD52K1039A CWD52K1040A
2 COMPRESSOR 1 ZR47K3PFJ522 ZR45KCTFD522 ZR57KCTFD599 ZR68KCTFD599
3 ANTI-VIBRATION BUSHING 4 CWH501020
4 NUT FOR COMP. MOUNT. 3 4582065
5 CRANKCASE HEATER 1 CWA341004 CWA341002
6 CONDENSER COMPLETE 1 CWB32C1094 CWB32C1095 CWB32C1096
7 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT07K1023 CWT07K1048 CWT07K1049
8 PIPE HOLDER RUBBER 1 CWG251016 CWG251021
9 CONDENSER SIDE PLATE 1 CWD911123
10 CONDENSER TOP PLATE 1 CWD911132 CWD911133
11 TUBE ASS’Y(PRESSURE SWITCH) 1 CWT022371 CWT022374
12 HIGH PRESSURE SWITCH 1 CWA101002
13 ACCUMULATOR 1 CWB131009A CWB131011A CWB131012A
13b TUBE ASS’Y(PRESS.SW + VALVE) 1 CWT022370 CWT022373
13c HEATING PRESSURE SWITCH CWA101001
13d 4-WAYS VALVE 1 CWB001014 CWB001015
15 TUBE ASS’Y(VALVE+STRAINER) 1 CWT022359 CWT022360 CWT022361
16 3-WAYS VALVE CWB011058
17 STRAINER CWB111005
17a 2-WAYS VALVE CWB02299
18 CAPILLARY TUBE for VALVE 1 CWB15K1037 CWB15K1039 CWB15K1040
19 PIPE HOLDER RUBBER 1 CWG251015
20 HOLDER-SERVICE VALVE 1 CWD911131
21 SOUND-PROOF BOARD ASS’Y 1 CWH15K1001
21a SOUND PROOF MATERIAL-COMP. 1 CWG302101 CWG302103
22 V-COIL COMPLETE 1 CWA43C2067
22a V-COIL COMPLETE-4 WAY VALVE 1 CWA43C2063
