Panasonic CS-A24BB4P Service Manual

23 PIPING SENSOR (DISCHARGE) 1 CWA501044
24 PIPING SENSOR (COIL) 1 CWA501045
25 SPRING FOR SENSOR 2 CWH711010
26 CABINET REAR PLATE 1 CWE021012A CWE02C1006
27 CONTROL BOARD 1 CWH141004
28 COMPRESSOR RELAY 1 CWA001006 CWA001005
29 TERMINAL BOARD ASS’Y 1 CWA28K1027 CWA28K1029
30 CAPACITOR-FAN MOTOR (3 / 460) 2 DS461305QP-A
30a CAPACITOR-COMP (MF/V) 1 DS371606CPNA
(60 / 370)
- - -
31 ELECTRONIC CONTROLLER 1 CWA742590 CWA742585
32 TRANSFORMER 1 CWA401029
33 CURRENT TRANSFORMER BOARD 1 CWA742591 CWA742592
34 BRACKET-FAN MOTOR 1 CWD541028
35 SCREW-BRACKET FAN MOTOR 4 CWH551040
36 FAN MOTOR 2 CWA951077 CWA951078
37 FAN MOTOR SUPPORTER 2 - CWD932142
38 SCREW-FAN MOTOR 8 CWH55442
39 PROPELLER FAN 2 CWH001007
40 WASHER for P.FAN 2 CWH571013
41 SPRING WASHER for P.FAN 2 XWB10B
42 NUT for PROPELLER FAN 2 CWH56033
43 P.FAN AIR GUIDER PLATE 1 CWE061042A CWE061044A
44 FAN GUARD 2 CWD041014A
45 CONDENSER GUARD 1 CWD041016A CWD041017A
46 CABINET TOP PLATE COMPLETE 1 CWE03C1004 CWE03C1005
47 FLARE NUT (3/8”) 1 CWT25005
48 FLARE NUT (6/8”) 1 CWT251012
49 PIPE COVER (FRONT) 1 CWD601017A
50 PIPE COVER (BACK) 1 CWD601018A
199
