Panasonic CS-A24BB4P Service Manual

51 CABINET FRONT PLATE 1 CWE061046A
52 HANDLE 3 CWE161008
53 HANDLE 1 CWE161009
54 LEADWIRE-COMPRESSOR 1 CWA67C3876 CWA67C3656
55 ACCESSORY COMPLETE 1 CWH82C1105
INSTALLATION INSTRUCTION 1 CWF612231
All parts are supplied from MACC, Malaysia (Vendor Code: 086)
NO. PART DESCRIPTION QTY. CU-C34BBP5 CU-C34BBP7 CU-C34BBP8 CU-C43BBP7 CU-C43BBP8 CU-
C50BBP7
1 BASE PAN ASS’Y 1 CWD52K1039A CWD52K1040A
2 COMPRESSOR 1 ZR47K3PFJ522 ZR45KCTF5522 ZR45KCTFD522 ZR57KCTF5599 ZR57KCTFD599
ZR68KCTF5599
3 ANTI-VIBRATION BUSHING 4 CWH501020
4 NUT FOR COMP. MOUNT. 3 CW4582065
5 CRANKCASE HEATER 1 CWA341004 CWA341002
6 CONDENSER COMPLETE 1 CWB32C1093 CWB32C1097
7 TUBE ASS’Y / (CAPILLARY
TUBE)
1 CWT07K1025 CWT07K1021
8 PIPE HOLDER RUBBER 1 CWG251016 CWG251021
8 PIPE HOLDER RUBBER 1 CWG251015
9 CONDENSER SIDE PLATE 1 CWD911123
10 CONDENSER TOP PLATE 1 CWD911132 CWD911133
11 TUBE ASS’Y (PRESSURE SW+
RCVR)
1 CWT022366 CWT022377
12 HIGH PRESSURE SWITCH 1 CWA101002
13 ACCUMULATOR 1 CWB131009A CWB131011A
CWB131012A
14 TUBE ASS’Y / (3 WAY VALVE-
GAS)
1 CWT022365 CWT022367
CWT022368
15 TUBE ASS’Y(VALVE+
STRAINER)
1 CWT022359 CWT022360
CWT022361
16 3-WAYS VALVE 1 CWB011058
17 STRAINER 1 CWB111005
200
