Panasonic CS-A24BB4P Service Manual

ITEM / MODEL
Indoor Unit Outdoor
unit
Main Body CS-A43BB4P CU-
C43BBP8
Panel CZ-BT01P
Remote CZ-RD51P (Wired)
Control CZ-RL01P (Wireless)
Cooling Capacity kW 12.5
BTU/h 42,700
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
Hi 30 Me 27 Lo 24 Hi 82
Medium and Low Speed cfm 1059 953 847 2895
Outside Dimension (H x W x D) mm 290 x 840 x 840 1220 x 1100
x
inch 11-7/16 x 33-1/24 x 33-1/24 48-1/24 x 43-5/
16
Net Weight kg 33 111
lbs 73 245
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm O.D Ø 20 I.D Ø 20
x
Compressor
Type, Number of Set - Hermetic-1 (
Scroll),
Starting Method - Direct on-line
starting
Motor Type - 2-pole 3-phase
induction
motor
Input kW - Cool
3.85
Rated
Output
kW - 3.5
Fan Type, Number of Set Turbo fan-1 Propeller
fan
Motor Type 6-pole single phase
induction motor
6-pole single
phase
induction
motor
Input kW 0.17 0.23
Rated
Output
kW 0.12 0.050 x
2
Air-heat Exchanger Slit-fin type Louvre-fin
type
Refrigerant Control Capillary tube -
Refrigerant Oil (Charged) litre -
SONTEX200LT(
Refrigerant (Charged) kg
-
(5.2)
lbs (11.5)
Running
Adjustment
Control Switch Wireless or Wired Remote
Control
-
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal
thermostat
fan motor, Crankcase heater, High pressure
switch,
Current transformer
Noise Level dB Hi 48 Me 46 Lo 44 Hi 55
1. Cooling capacities are based on indoor temperature of 27°C D.B.
(80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
35

Panasonic CS-A24BB4P Specifications

General

Brand	Panasonic
Model	CS-A24BB4P
Category	Air Conditioner
Language	English
