Panasonic CS-A24BB4P Service Manual

temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
ELECTRICAL DATA (50Hz)
ITEM / MODEL CS-A43BB4P, CU-C43BBP8
Condition by JIS B 8615
Volts V 380 400
415
Phase 3N 3N
3N
Power Consumption kW Cool 4.25 4.25
4.25
Running Current A Cool 7.30 7.30
7.30
Starting Current A 58 58 58
Power Factor % Cool 88 84 81
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 3N~380V, 400V, 415V
50Hz
4.10. CS-A50BB4P / CU-C50BBP7
ITEM / MODEL
Indoor Unit Outdoor
unit
Main Body CS-A50BB4P CU-
C50BBP7
Panel CZ-BT01P
Remote CZ-RD51P (Wired)
Control CZ-RL01P (Wireless)
Cooling Capacity kW 15.1
BTU/h 51,500
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
Hi 31 Me 26 Lo 22 Hi 86
Medium and Low Speed cfm 940 788 667 3036
Outside Dimension (H x W x D) mm 290 x 840 x 840 1220 x 1100
x
inch 11-7/16 x 33-1/24 x 33-1/24 48-1/24 x 43-5/16
x
Net Weight kg 33 114
lbs 73 251
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm O.D Ø 20 I.D Ø 20
x1
Compressor
Type, Number of Set - Hermetic-1 (
Scroll),
Starting Method - Direct on-line
starting
Motor Type - 2-pole 3-phase
induction
motor
Input kW - Cool
5.55
Rated
Output
kW - 4.1
36
