50
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
[PHAAM] Printed in Malaysia
SSBZ0604-02
REF. NO. PART NAME & DESCRIPTION QTY. CU-C12EKF REMARKS
1 CHASSY ASS’Y 1 CWD50K2088
2 SOUND PROOF MATERIAL 1 CWG302110
3 FAN MOTOR BRACKET 1 CWD541030
4 SCREW - FAN MOTOR BRACKET 2 CWH551059J
5 FAN MOTOR, AC 36W SINGLE 1 CWA951120 0
6 SCREW - FAN MOTOR MOUNT 3 CWH55406J
7 PROPELLER FAN ASS’Y 1 CWH03K1006
8 NUT - PROPELLER FAN 1 CWH56053J
9 COMPRESSOR (50HZ, 220/240V) 1 2KS210D3BA02 0
10 ANTI - VIBRATION BUSHING 3 CWH50055
11 NUT - COMPRESSOR MOUNT 3 CWH561049
12 CONDENSER 1 CWB32C1152
13 CAPILLARY TUBE ASS’Y 1 CWB15K1165
14 STRAINER 1 CWB111011
15 HOLDER COUPLING 1 CWB351023
16 2-WAY VALVE (LIQUID) 1 CWB021116 0
17 3-WAY VALVE (GAS) 1 CWB011148 0
18 OVERLOAD PROTECTOR 1 CWA121202J
19 TERMINAL COVER 1 CWH171011
20 NUT - TERMINAL COVER 1 CWH7080300J
21 SOUND PROOF BOARD 1 CWH151023
22 CONTROL BOARD 1 CWH102202
23 TERMINAL BOARD ASS’Y 1 CWA28K1064J
24 CAPACITOR - COMPRESSOR (35μF, 370V) 1 DS371356CPNA 0
25 HOLDER CAPACITOR 1 CWH30057
26 CAPACITOR - FAN MOTOR (2.0μF, 440V) 1 DS441205NPQA 0
27 CABINET SIDE PLATE (L) 1 CWE041031A
28 CABINET SIDE PLATE (R) 1 CWE041037A
29 CABINET FRONT PLATE 1 CWE06K1034
30 WIRE NET COMPLETE 1 CWD04C1007
31 CABINET TOP PLATE 1 CWE031014A
32 PLATE - C. B. COVER 1 CWH131088
33 CONTROL BOARD COVER 1 CWH13C1065
34 HANDLE 1 CWE161010
35 OPERATION INSTRUCTIONS 1 CWF565084
36 INSTALLATION INSTRUCTIONS 1 CWF612901
