Panasonic CS-C18BKP Service Manual

Unit CS-C24BK CU-C24BK
Electrical Data Input Power kW (1)
(7)
2.60 - 2.41
(2) 2.55
(3) 2.64 - 2.54
(4) 2.41
(5)
(6)
2.68 - 2.64
Running Current A (1)
(7)
12.4 - 11.8
(2) 12.0
(4) 11.8
(5)
(6)
12.1 - 13.1
EER W/W (BTU/hW) (1)
(7)
2.70 - 2.92 (9.23 - 9.96)
(2) 2.76 (9.41)
(3) 2.60 - 2.70 (8.86 - 9.21)
(4) 2.92 (9.96)
(5)
(6)
2.5 - 2.6 (8.6 - 8.7)
Starting Current A (1)
(7)
65.0
(2)
(4)
(5)
(6)
63.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 5/8”
L ; Half Union 1/4”
G ; 3-way valve 5/8”
L ; 3-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 5/8”
L ; (liquid side) 1/4”
G ; (gas side) 5/8”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire 3 (2.5 mm
2
) —
Dimensions Height inch (mm) 10 - 13/16 (275) 26 - 31/32 (685)
Width inch (mm) 39 - 9/32 (998) 31 - 1/2 (800)
Depth inch (mm) 8 - 9/32 (210) 11 - 13/16 (300)
Net Weight lb (kg) (1)
(3)
(4)
(7)
24 (11.0) 132 (60.0)
(2)
(5)
(6)
24 (11.0) 133 (60.5)
Compressor Type — Rotary (1 cylinder) rolling
piston type
Motor Type — Induction (2-poles)
Rated Output kW (1)
(4)
(7)
— 2.2
(2)
(5)
(6)
— 1.8
11
CS-C18BKP CU-C18BKP5 / CS-C18BKP CU-C18BKP6 / CS-C24BKP CU-C24BKP5 / CS-C24BKP CU-C24BKP6
