Panasonic CS-C18BKP Service Manual

Unit CS-C18BK CU-C18BK
Power level dB (1) 54 - 54 70 - 70
(2)
(4)
(5)
(6)
(7)
— —
(3) 54 - 54 71 - 70
Electrical Data Input Power kW (1)
(7)
1.76 - 1.72
(2)
(4)
1.72
(3) 1.81 - 1.78
(5)
(6)
1.78 - 1.74
Running Current A (1)
(7)
7.8 - 8.0
(2)
(4)
8.0
(5)
(6)
7.9 - 8.5
EER W/W (BTU/hW) (1)
(7)
3.01 - 3.08 (10.28 - 10.52)
(2)
(4)
3.08 (10.52)
(3) 2.93 - 2.98 (10.00 - 10.17)
(5)
(6)
2.9 - 3.0 (9.9 - 10.1)
Starting Current A (1)
(7)
38.0
(2)
(5)
(6)
47.0
(4) 36.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 1/2”
L ; Half Union 1/4”
G ; 3-way valve 1/2”
L ; 3-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire 3 (1.5 mm
2
) —
Dimensions Height inch (mm) 10 - 13/16 (275) 26 - 31/32 (685)
Width inch (mm) 39 - 9/32 (998) 31 - 1/2 (800)
Depth inch (mm) 8 - 9/32 (210) 11 - 13/16 (300)
Net Weight lb (kg) (1)
(3)
(4)
(7)
24 (11.0) 121 (55.0)
(2)
(5)
(6)
24 (11.0) 106 (48.0)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output kW (1)
(3)
(4)
(7)
— 1.5
(2)
(5)
(6)
— 1.2
7
CS-C18BKP CU-C18BKP5 / CS-C18BKP CU-C18BKP6 / CS-C24BKP CU-C24BKP5 / CS-C24BKP CU-C24BKP6

Panasonic CS-C18BKP Specifications
