18 Replacement Parts List (Outdoor Unit)
18.1. CU-C18DKD CU-C24DKD
REF. NO. PART NAME & DESCRIPTION QTY. CU-C18DKD CU-C24DKD REMARKS
1 CHASSY ASS’Y 1 CWD50K2072 CWD50K2100
2 COMPRESSOR 1 2KS314D5AA02 2JS438D3GA02 0
3 ANTI - VIBRATION BUSHING 3 CWH50049 CWH50055
4 NUT - COMPRESSOR MOUNT 3 CWH4582065
←
5 PACKING 3 - CWB81043
6 CONDENSER 1 CWB32C1267 CWB32C1591
7 SOUND PROOF BOARD ASS’Y 1 CWH15K1018 CWH151051
8 FAN MOTOR BRACKET 1 CWD541030 CWD541065
9 SCREW - FAN MOTOR BRACKET 2 CWH551060
←
10 FAN MOTOR 1 CWA951264 CWA951383 0
11 SCREW - FAN MOTOR MOUNT 3 CWH55406 CWH55252
12 PROPELLER FAN ASS’Y 1 CWH03K1006 CWH03K1017
13 NUT - PROPELLER FAN 1 CWH56053 CWH561038
14 HOLDER COUPLING 1 CWH351046 CWH351036
15 3-WAY VALVE (LIQUID) 1 CWB021242 CWB021175 0
16 TUBE ASS’Y (CAPILLARY TUBE) 1 CWB15K1103 CWT023596
17 3-WAY VALVE (GAS) 1 CWB011233 CWB011213 0
18 TERMINAL COVER 1 CWH171012
←
19 NUT - TERMINAL COVER 1 CWH7080300
←
20 CONTROL BOARD CASING 1 CWH102202 CWH102206
21 CAPACITOR-F.M 1 DS441205NPQA DS441355BPQE 0
22 CAPACITOR - COMP 1 CWA312078 CWA312079 0
23 HOLDER CAPACITOR 1 CWH30060
←
24 TERMINAL BOARD ASS’Y 1 CWA28K1064
←
25 CABINET SIDE PLATE (L) 1 CWE041031A CWE041082A
26 HANDLE 1 CWE161010
←
27 CABINET SIDE PLATE (R) 1 CWE041101A CWE041083A
28 HANDLE 2 - CWE16000E
29 CABINET FRONT PLATE ASS’Y 1 CWE06K1034 CWE06K1043
30 WIRE NET COMPLETE 1 CWD04C1008 CWD041041A
31 CABINET TOP PLATE ASS’Y 1 CWE031014A CWE03K1009A
32 CONTROL BOARD COVER 1 CWH131088 CWH131168
33 CONTROL BOARD COVER COMPLETE 1 CWH13C1065 CWH131169A
34 OPERATION INSTRUCTIONS 1 CWF564447
←
35 INSTALLATION INSTRUCTIONS 1 CWF612650 CWF612685
36 THERMOSTAT 1 - CWA151040 0
37 STRAINER 1 CWB11004 CWB11025
38 SOUND PROOF MATERIAL 1 CWG302256 CWG302278
39 INSTALLATION INSTRUCTIONS 1 CWF612654 CWF612686
40 INSTALLATION INSTRUCTIONS 1 CWF612719 CWF612718
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
64
CS-C18DKD CU-C18DKD / CS-C24DKD CU-C24DKD
