Panasonic CS-C18DKD - Page 9

Unit CS-C24DKD CU-C24DKD
Protection Device — Inner Protector
Capillary Tube Length mm — 754
Flow Rate l/min — 22.0
Inner Diameter mm — 2.0
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 45 µF, 400/440VAC
Fan Motor Capacitor µF, VAC — 3.5 µF, 440VAC
Note:
• Specifications are subject to change without notice for further improvement.
9
CS-C18DKD CU-C18DKD / CS-C24DKD CU-C24DKD
