– 10 –
MAC9512086C2
CS-C181KE
Refrigeration Cycle Diagram
CS/CU-C181K
CS/CU-C241K
THERMOSTAT
PROCESS TUBE
STRAINER
LIQUID SIDE
GAS SIDE
3-WAY VALVE
3-WAY VALVE
INDOOR UNIT OUTDOOR UNIT
HEAT EXCHANGER
(EVAPORATOR)
SENSOR
INTAKE
TEMP.
SENSOR
PIPE
TEMP.
CAPILLARY TUBE
CAPILLARY TUBE
COMPRESSOR
OIL
SEPARATOR
HEAT EXCHANGER
(CONDENSER)
ACCUMULATOR (SUB)
(CU-C241K ONLY)
AIR
ONLY OIL
Dimensions
CU-C181K / CU-C241K
7577.5
130130 540
663
685
330
370
56.3800
300
35
Air intake direction
Air outlet direction Slots (12 x 17) Four places
3-way valve at
liquid side
3-way valve at
gas side
22
106.5
70cm
10cm
10cm
Required space for installation
Anchor bolt pitch 280 x 570
Unit : mm
