Panasonic CS-C9KKV - Indoor Unit

6
1
INDOOR UNIT
• Wipe the unit gently with a soft, dry cloth.
2
FRONT PANEL
Remove Front Panel
• Raise and pull to remove the front panel.
• Wash gently and dry.
Close Front Panel
• Press down both ends of the front panel to close it
securely.
3
REMOTE CONTROL RECEIVER
4
ALUMINIUM FIN
5
ECO PATROL SENSOR
6
HORIZONTAL AIRFLOW DIRECTION LOUVER
C9KKV, C9KKV-6, C12KKV, C12KKV-6
• Manually adjustable.
C18KKV, C18KKV-6, C24KKV, C24KKV-6,
C28KKV, C28KKV-6
• Do not adjust by hand.
7
VERTICAL AIRFLOW DIRECTION LOUVER
• Do not adjust by hand.
8
AUTO OFF/ON BUTTON
• Use when remote control is misplaced or a malfunction
occurs.
Action Mode
Press once. Auto
Press and hold until 1 beep is
heard, then release.
Cooling
Press the button to turn off.
9
e-ion CHARGING WIRE
10
e-ion FILTERS
• Clean the fi lters regularly.
• Wash/rinse the fi lters gently with water to avoid damage
to the fi lter surface.
• Dry the fi lters thoroughly under the shade, away from
fi re or direct sunlight.
• Replace any damaged fi lters.
11
ACTIVE e-ion GENERATOR
Clean with dry cotton bud.
• Active e-ion generator cleaning is
recommended every 6 months.
CAUTION
• Switch off the power supply before cleaning.
• Do not touch the aluminium fi n, sharp parts may cause injury.
INDOOR UNIT
2
3
5
7
4
6
9
,
10
,
11
e-ion AIR PURIFYING
SYSTEM
• Do not touch during operation
8
1
9
10
11
5
ECO PATROL SENSOR
• Do not hit or violently press the
sensor or poke it with a sharp
object. This can lead to damage
and malfunction.
• Do not place large objects near
the sensor and keep heating units
or humidifi ers off the sensor’s
detection area. This may lead to
sensor malfunction.
CLEANING INSTRUCTIONS
CLEANING INSTRUCTIONS
HINT
HINT
• Do not use benzene, thinner or scouring powder.
• Use only soap ( pH7) or neutral household detergent.
• Do not use water hotter than 40°C.
• To ensure optimal performance of the unit, cleaning
maintenance has to be carried out at regular intervals.
Please consult authorized dealer.
