6
Indoor CS-C9PKV CS-C12PKV
Model
Outdoor CU-C9PKV CU-C12PKV
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 7.5 (24.6) 7.5 (24.6)
Length range (min – max) m (ft) 3 (9.8) ~ 10 (32.8) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 5 (16.4) 5 (16.4)
Additional Gas Amount g/m (oz/ft) 10 (0.1) 10 (0.1)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Inner Diameter mm 16.7 16.7
Drain Hose
Length mm 650 650
Fin Material Pre Coat Pre Coat
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 15 × 21 2 × 15 × 21
Indoor Heat
Exchanger
Size (W × H × L) mm 610 × 315 × 25.4 610 × 315 × 25.4
Fin Material Blue Coated Blue Coated
Fin Type Louver Fin Louver Fin
Row × Stage × FPI 1 × 17 × 17 1 × 20 × 17
Outdoor Heat
Exchanger
Size (W × H × L) mm 22 × 482.6 × 567.4 22 × 508 × 814.4
Material Polypropelene Polypropelene
Air Filter
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 10 10
Thermostat – –
Protection Device 2-Stage Overload Protector 2-Stage Overload Protector
Dry Bulb Wet Bulb Dry Bulb Wet Bulb
Maximum °C 32 23 32 23
Indoor Operation Range
Minimum °C 16 11 16 11
Maximum °C 43 26 43 26
Outdoor Operation Range
Minimum °C 16 11 16 11
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C Dry Bulb (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb)
2.
Specifications are subjected to change without prior notice for further improvement.
