2. Specification
Indoor CS-C9PKV CS-C12PKV
Model
Outdoor CU-C9PKV CU-C12PKV
Performance Test Condition NEW JIS NEW JIS
Phase, Hz Single, 60 Single, 60
Power Supply
V 220 220
kW 2.65 3.56
BTU/h 9040 12100
Capacity
kJ/h 9540 12820
Running Current A 3.9 5.3
Input Power W 830 1.11k
W/W 3.19 3.21
EER
BTU/hW 10.89 10.90
Power Factor % 97 95
dB-A 36 / 26 39 / 29
Indoor Noise (H / L)
Power Level dB 49 / – 52 / –
dB-A 48 / – 48 / –
Cooling
Outdoor Noise (H / L)
Power Level dB 63 / – 63 / –
Max Current (A) / Max Input Power (W) 4.6 / 990 6.5 / 1.35k
Starting Current (A) 23.0 33.0
Type Hermetic Motor / Rotary Hermetic Motor / Rotary
Motor Type Induction (2-poles) Induction (2-poles)
Compressor
Output Power W 600 850
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type AC / Induction (4-poles) AC / Induction (4-poles)
Input Power W 54.9 54.9
Output Power W 22 22
QLo rpm 570 660
Lo rpm 640 730
Me rpm 830 910
Hi rpm 1010 1090
Indoor Fan
Speed
SHi rpm 1110 1110
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type AC / Induction (6-poles) AC / Induction (6-poles)
Input Power W 74.8 86.7
Output Power W 30 30
Outdoor Fan
Speed Hi rpm 800 800
Moisture Removal L/h (Pt/h) 1.6 (3.4) 2.1 (4.4)
QLo m
3
/min (ft
3
/min) 5.4 (189) 6.3 (222)
Lo m
3
/min (ft
3
/min) 6.0 (213) 7.0 (246)
Me m
3
/min (ft
3
/min) 7.8 (276) 8.7 (307)
Hi m
3
/min (ft
3
/min) 9.5 (335) 10.4 (367)
Indoor Airflow
SHi m
3
/min (ft
3
/min) 10.4 (369) 10.6 (374)
Outdoor Airflow Hi m
3
/min (ft
3
/min) 29.2 (1030) 32.4 (1140)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
ATMOS M60 or SUNISO 4GDID (290) ATMOS M60 or SUNISO 4GDID (350)
Refrigeration
Cycle
Refrigerant Type g (oz) R22, 590 (20.8) R22, 770 (27.2)
Height(I/D / O/D) mm (inch) 290 (11-7/16) 511 (20-1/8) 290 (11-7/16) 542 (21-11/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) 650 (25-19/32) 870 (34-9/32) 780 (30-23/32)
Dimension
Depth (I/D / O/D) mm (inch) 214 (8-7/16) 230 (9-1/16) 214 (8-7/16) 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) 22 (49) 9 (20) 30 (66)
