Panasonic CS-E15CKP Service Manual

Table on Shifting Frequency Zone
Temperature, X (°C) Zone Frequency No. Shifting:
(Intake Air - Internal Setting) Cooling Mode / Soft Dry Mode Heating Mode
X -2.5 0 Shift to Freq. MIN Shift to Freq. MAX
-2.5 X -1.5 1 Shift to Freq. MIN Shift to Freq. MAX
-1.5 X -1.0 2 -2 Freq. No. +2 Freq. No.
-1.0 X -0.5 3 -1 Freq. No. +1 Freq. No.
-0.5 X +1.0 4 Same Freq. No. Same Freq. No.
+0.5 X +1.0 5 +1 Freq. No. -1 Freq. No.
+1.0 X +1.5 6 +2 Freq. No. -2 Freq. No.
+1.5 X +2.5 7 Shift to Freq. MAX Shift to Freq. MIN
X +2.5 8 Shift to Freq. MAX Shift to Freq. MIN
Besides, the range of operation frequency will change according to the setting environment as listed below:
Condition: Freq. no. for E9CKP Freq. no. for E12CKP/E15CKP Remarks
MIN MAX MIN MAX
Cooling Mode 1 15 1 16 (a)
- if remote controller set 28°C & fan speed =
Hi
7 15 7 16 (a), (c)
- if remote controller set 28°C & fan speed =
Me-, Me, Me+, Auto
5 15 6 16 (a), (c)
- if remote controller set 28°C & fan speed =
Lo
4 15 5 16 (a), (c)
- if Powerful Mode ON 7 15 7 16 (a), (c)
Soft Dry Mode 4 7 4 8
Heating Mode 1 30 1 30 (b)
- if remote controller set 18°C & fan speed =
Hi
10 30 10 30 (b), (d)
- if remote control set 18°C & fan speed =
Me-, Me, Me+, Auto
9 30 9 30 (b), (d)
- if remote controller set 18°C & fan speed =
Lo
8 30 8 30 (b), (d)
- if Powerful Mode ON 10 30 10 30 (b), (d)
Remark:
(a) If frequency decreases from MAX, the following frequency performed will be depending to outdoor temperature, as given in below table
(for 30 seconds only) and then continues as normal rule.
Outdoor Temperature, X (°C) Frequency No.
X 30 13
X 30 7
(b) (If frequency increases from Freq. No. 17, the following frequency performed is as below (for 30 seconds only) and then continue as
normal rule.
Outdoor Temperature, X (°C) Frequency No.
X 10 10
X X 10 13
X 4 17
(c) When temperature different (intake - setting) < -1.0 °C or Thermo-Off activated and only valid for 120 seconds; not applicable during Soft
Dry Mode, and Anti-freezing control.
(d) When temperature different (intake - setting) > +1.5 °C or Thermo-Off activated and only valid for 130 seconds.
16
CS-E15CKP CU-E15CKP5
