15 Replacement Parts List
<Model: CS-E15CKP>
REF NO. DESCRIPTION & NAME QTY. CS-E15CKP REMARKS
1 CHASSY COMPLETE 1 CWD50C1246
2 FAN MOTOR 1 CWA981056 O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1012
4 SCREW - CROSS-FLOW FAN 1 CWH4580304
5 BEARING ASSY 1 CWH64K007
6 EVAPORATOR 1 CWB30C1260
7 FLARE NUT (1/4) 1 CWH6002140
8 FLARE NUT 1 CWT25007 (1/2)
9 ANTI-VIBRATION BUSHING 1 -
10 INTAKE AIR SENSOR HOLDER 1 CWH32142
11 DISCHARGE GRILLE COMPLETE 1 CWE20C2120
12 VANE 12 CWE241088
13 CONNECTING BAR 2 CWE261035
14 AIR SWING MOTOR 2 CWA98260 O
15 LEADWIRE 1 CWA67C3849
16 FULCRUM 1 CWH621013
17 LEADWIRE - AIR SWING MOTOR 1 CWA67C3977
18 CAP COMPLETE 1 CWH52C1001
19 VANE 1 CWE241070
20 PARTICULAR PIECE 1 CWD932162
21 CONTROL BOARD 1 CWH102103
22 TERMINAL BOARD COMPLETE 1 CWA28C2128 O
23 POWER SUPPLY CORD 1 CWA20C2238
24 ELECTRONIC CONTROLLER-MAIN 1 CWA73C1409 O
25 ELECTRONIC CONTROLLER -P.SUPPLY 1 CWA742616 O
26 PCB RECEIVER 1 CWA742724
27 INDICATOR COMPLETE 1 CWE39C1067
28 INDICATOR HOLDER 1 CWD932163
29 SENSOR COMPLETE 1 CWA50C2122 O
30 CONTROL BOARD COVER (TOP) 1 CWH131091
31 CONTROL BOARD COVER (FRONT) 1 CWH131090
32 REMOTE CONTROL COMPLETE 1 CWA75C2295 O
33 FRONT GRILLE COMPLETE 1 CWE11C2756
34 INTAKE GRILLE 1 CWE22C1081
35 GRILLE DOOR 1 CWE141033
36 DECORATION BASE (RIGHT) 1 CWE351067
37 DECORATION BASE (LEFT) 1 CWE351068
38 AIR FILTER 2 CWD001047
39 CONTROL PANEL 1 CWE312291
40 SCREW FOR FRONT GRILLE 2 XTN4+16C
41 CAP FOR FRONT GRILLE 2 CWH521062
42 DRAIN HOSE 1 CWH85285
43 INSTALLING HOLDER ASSY 1 CWH36K1006
44 BAG COMPLETE FOR INSTALLATION 1 CWH82C067
45 AIR PURIFYING FILTER 1 CWMD00C0001 O
46 TRIPLE DEODORIZING FILTER 1 CWMD00C0004 O
47 ELECTRONIC CONTROLLER - IONIZER 1 CWA743099
48 CASING - IONIZER 1 CWD932228
49 ION GENERATOR 1 CWH94C0001
(Note)
• All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
78
CS-E15CKP CU-E15CKP5
