Panasonic CS-E15NKEW Service Manual

144
 Piping Length Characteristic
[Condition] Indoor temperature: 20/-°C, 7/6°C
Remote condition: High fan speed, Heat 30°C
Comp. Hz: F
h
3.250
3.300
3.350
3.400
3.450
3456789101112131415
Piping Length (m)
Heating
Capacity (kW)
3.320
3.340
3.360
3.380
3.400
3.420
3456789101112131415
Piping Length (m)
Current
(A)
2.340
2.360
2.380
2.400
3 4 5 6 7 8 9 10 11 12 13 14 15
Piping Length (m)
Gas Side Piping Pressure (MPa
)
34.400
34.500
34.600
34.700
34.800
34.900
3456789101112131415
Piping Length (m)
Outlet Air
Temperature (°C
)
230
