Panasonic CS-E15NKEW Service Manual

181
REF.
NO.
PART NAME & DESCRIPTION QTY. CS-E18NKEW CS-E21NKEW CS-XE18NKEW CS-XE21NKEW REMARK
1 CHASSIS COMPLETE 1 CWD50C1654 ← CWD50C1604 ←
2 FAN MOTOR 1 ARW7627AC ← ← ← o
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1077 ← ← ←
4 BEARING ASSY 1 CWH64K007 ← ← ← o
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ← ← ←
6 GENERATOR COMPLETE 1 CWH94C0043 ← ← ←
7 EVAPORATOR 1 CWB30C3860 ← ← ←
8 FLARE NUT (LIQUID) 1 CWT251030 ← ← ←
9 FLARE NUT (GAS) 1 CWT251032 ← ← ←
10 CLIP FOR SENSOR 1 CWH32143 ← ← ←
11 CONTROL BOARD CASING 1 CWH102449 ← ← ←
12 TERMINAL BOARD COMPLETE 1 CWA28C2357 ← ← ← o
13
ELECTRONIC CONTROLLER -
MAIN
1 CWA73C6645 CWA73C6646 CWA73C6645 CWA73C6646 o
14
ELECTRONIC CONTROLLER -
HVU
1 N0GE1F000002 ← ← ←
15
ELECTRONIC CONTROLLER -
INDICATOR & RECEIVER
1 CWA746634 ← ← ← o
16 SENSOR COMPLETE 1 CWA50C2401 ← ← ← o
17 SENSOR COMPLETE (ECO) 1 CWA50C2826 ← ← ← o
18
ELECTRONIC CONTROLLER
(ECO SENSOR)
1 CWA745791 ← ← ←
19
ELECTRONIC CONTROLLER
(ECO SENSOR)
1 CWA746206 ← ← ←
20
ELECTRONIC CONTROLLER
(COMPARATOR)
1 CWA746653 ← ← ←
21 LEAD WIRE - PCB ECO 1 CWA67C9934 ← ← ←
22
CONTROL BOARD CASING FOR
PCB ECO
1 CWD933407A ← ← ←
23 CONTROL BOARD TOP COVER 1 CWH131467 ← ← ←
24 INDICATOR HOLDER 1 CWD933406 ← ← ←
25
CONTROL BOARD FRONT
COVER CO.
1 CWH13C1247 ← ← ←
26 DISCHARGE GRILLE COMPLETE 1 CWE20C3242 ← CWE20C3244 ←
27 BACK COVER CHASSIS 1 CWD933031 ← CWD933031A ←
28 FULCRUM 2 CWH621138 ← ← ←
29 VERTICAL VANE 11 CWE241374 ← ← ←
30 CONNECTING BAR (RIGHT) 1 CWE261257 ← ← ←
31 CONNECTING BAR (LEFT) 1 CWE261258 ← ← ←
32 AIR SWING MOTOR 1 CWA98K1018 ← ← ← o
33 AIR SWING MOTOR 1 CWA981241 ← ← ← o
34 CAP - DRAIN TRAY 1 CWH521096 ← ← ←
35 HORIZONTAL VANE COMPLETE 1 CWE24C1392 ← CWE24C1395 ←
36 REMOTE CONTROL COMPLETE 1 CWA75C3887 ← ← ← o
37 FRONT GRILLE COMPLETE 1 CWE11C5091 ← CWE11C5129 ← o
38 INTAKE GRILLE COMPLETE 1 CWE22C1728 ← CWE22C1729 ←
39 GRILLE DOOR COMPLETE 1 CWE14C1090 ← CWE14C1091 ←
40 AIR FILTER 2 CWD001283 ← ← ← o
41 SCREW - FRONT GRILLE 3 XTT4+16CFJ ← ← ←
42 CAP - FRONT GRILLE 3 CWH521227 ← CWH521227A ←
43 DRAIN HOSE 1 CWH851173 ← ← ←
44 INSTALLATION PLATE 1 CWH361098 ← ← ←
45
BAG COMPLETE - INSTALLATION
SCREW
1 CWH82C1705 ← ← ←
46 OPERATING INSTRUCTION 1 CWF56C7825 ← ← ←
50 BAG 1 CWG861498 ← ← ←
51 SHOCK ABSORBER ( L ) 1 CWG713402 ← ← ←
