Panasonic CS-E15NKEW Service Manual

6
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type Transistor (8-poles) Transistor (8-poles)
Input Power W 94.8 94.8
Output Power W 40 40
Cool rpm 560 600
QLo
Heat rpm 600 640
Cool rpm 640 700
Lo
Heat rpm 700 790
Cool rpm 845 930
Me
Heat rpm 895 1015
Cool rpm 1050 1160
Hi
Heat rpm 1090 1240
Cool rpm 1080 1210
Indoor Fan
Speed
SHi
Heat rpm 1120 1250
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type Induction (6-poles) Induction (6-poles)
Input Power W - -
Output Power W 25 25
Outdoor Fan
Speed Hi rpm 750 770
Moisture Removal L/h (Pt/h) 1.3 (2.7) 1.5 (3.2)
Cool m
3
/min (ft
3
/min) 5.15 (182) 5.00 (177)
QLo
Heat m
3
/min (ft
3
/min) 5.60 (198) 5.00 (177)
Cool m
3
/min (ft
3
/min) 6.10 (215) 6.15 (217)
Lo
Heat m
3
/min (ft
3
/min) 6.80 (240) 6.65 (235)
Cool m
3
/min (ft
3
/min) 8.50 (300) 8.70 (307)
Me
Heat m
3
/min (ft
3
/min) 9.10 (321) 9.20 (325)
Cool m
3
/min (ft
3
/min) 10.9 (385) 11.3 (400)
Hi
Heat m
3
/min (ft
3
/min) 11.4 (400) 11.7 (415)
Cool m
3
/min (ft
3
/min) 11.60 (410) 11.70 (413)
Indoor
Airflow
SHi
Heat m
3
/min (ft
3
/min) 12.00 (424) 12.10 (427)
Cool m
3
/min (ft
3
/min) 33.9 (1195) 29.8 (1050)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 33.9 (1195) 29.8 (1050)
Control Device Check Valve & Capillary Tube Check Valve & Capillary Tube
Refrigerant Oil cm
3
FV50S (320) FV50S (320)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 830 (29.3) R410A, 950 (33.5)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 542 (21-11/32) 290 (11-7/16) / 542 (21-11/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 780 (30-23/32) 870 (34-9/32) / 780 (30-23/32)
Dimension
Depth (I/D / O/D) mm (inch) 214 (8-7/16) / 289 (11-13/32) 214 (8-7/16) / 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 32 (71) 9 (20) / 33 (73)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 9.52 (3/8)
Standard length m (ft) 5 (16.4) 5 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 15.0 (49.2) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
