41
2. Heating
Note:
a. UP:
• If move from Lo, the fan speed will be shifted to Maximum 1,520 rpm.
• If move from Maximum, the fan speed no change.
• In up zone, 10 rpm is added for every 10s until Maximum 1,520 rpm.
b. DOWN:
• The fan speed will be decreased one step every 10 sec. until Minimum 1,270 rpm.
c. Current Output Fixed:
• Maintain at present fan speed.
d. Instantaneous Maximum:
• Fan speed will be increased to maximum auto fan speed.
e. Temperature in ( ) is for Powerful Mode operation.
9.6. Airflow Direction Control
9.6.1. Air Outlet Selection
• When the Air Outlet Selection Switch is turned to ON, air is blown out from both upper and lower air outlet.
• When the Air Outlet Selection Switch is turned to OFF, air is blown out from upper air outlet only.
(Fig. a)
Model No. A No. B No. C
Powerful Program CS-E9GFEW 1090 1110 1130
CS-E12GFEW 1090 1110 1130
CS-E18GFEW 1210 1230 1250
Normal Program CS-E9GFEW 1050 1070 1090
CS-E12GFEW 1050 1070 1090
CS-E18GFEW 1170 1190 1210
Quiet Program CS-E9GFEW 1030 1050 1070
CS-E12GFEW 1030 1050 1070
CS-E18GFEW 1150 1170 1190
(rpm)
