8
2.1.3. CS-E18GFEW CU-E18GFE
ITEM UNIT CS-E18GFEW CU-E18GFE
Cooling Capacity
kW 5.00 (0.90 ~ 5.60)
kCal/h 4,300 (780 ~ 4,820)
BTU/h 17,100 (3,100 ~ 19,100)
Heating Capacity
kW 5.80 (0.90 ~ 7.10)
kCal/h 4,990 (780 ~ 6,100)
BTU/h 19,800 (3,100 ~ 24,200)
Moisture Removal
l/h 2.8
pt/h (5.9)
Power Source
Phase Single
V 220 / 230 / 240
Cycle 50
Airflow Method OUTLET
INTAKE
SIDE VIEW
TOP VIEW
Air Volume
Indoor Air (Lo)
m
3
/min (cfm)
Cooling; 8.3 (293)
—
Heating; 8.5 (300)
Indoor Air (Me)
m
3
/min (cfm)
Cooling; 9.9 (350)
—
Heating; 10.8 (381)
Indoor Air (Hi)
m
3
/min (cfm)
Cooling; 11.0 (388) Cooling; 40.0 (1,410)
Heating; 13.0 (459) Heating; 40.0 (1,410)
Noise Level
dB (A)
Cooling; High 44, Low 36 Cooling; 47
Heating; High 44, Low 36 Heating; 48
Power Level dB
Cooling; High 60 Cooling; 60
Heating; High 62 Heating; 61
Electrical Data
Input W
Cooling; 1,550 (255 - 1,910)
Heating; 1,600 (260 - 2,350)
Running Current A
Cooling; 7.20 / 7.00 / 6.90
Heating; 7.35 / 7.10 / 6.95
EER W/W(kcal/hw), BTU/hw Cooling; 3.23 (2.78), 11.0
COP W/W(kcal/hw), BTU/hw Heating; 3.63 (3.12), 12.4
Starting Current A 7.35
Piping Connection Port
(Flare piping)
inch G; Half Union 1/2" G; 3-way valve 1/2"
inch L; Half Union 1/4" L; 2-way valve 1/4"
Piping Size
(Flare piping)
inch G; (gas side); 1/2" G; (gas side); 1/2"
inch L; (liquid side); 1/4" L; (liquid side); 1/4"
Drain Hose
Inner diameter mm 15 —
Length m 220 —
Power Cord Length — —
Number of core-wire — —
Dimensions
Height (inch) mm 23-5/8 (600) 29-17/32 (750)
Width (inch) mm 27-9/16 (700) 34-7/16 (875)
Depth (inch) mm 8-9/32 (210) 13-19/32 (345)
Net Weight Ib (kg) 31 (14) 82 (37)
Compressor
Type —
Brushless (4-poles)Motor Type —
Rated Output W —
