Panasonic CS-E7JKEW Service Manual

150
18.2. Sensible Capacity Chart
O
CU-E7JKE CU-E7JKE-3
O
CU-E9JKE CU-E9JKE-3
O
CU-E12JKE CU-E12JKE-3
O
CU-E15JKE
O CU-E15JKE-1
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TCSHCIPTCSHCIPTCSHCIPTCSHCIP
17.0°C 2.03 1.54 0.43 1.90 1.48 0.46 1.77 1.42 0.50 1.61 1.35 0.53
19.0°C 2.05 0.47
19.5°C 2.23 1.61 0.44 2.09 1.55 0.47 1.94 1.49 0.50 1.77 1.42 0.54
22.0°C 2.43 1.67 0.45 2.27 1.61 0.48 2.12 1.55 0.51 1.92 1.48 0.55
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TCSHCIPTCSHCIPTCSHCIPTCSHCIP
17.0°C 2.48 1.88 0.50 2.32 1.80 0.54 2.16 1.73 0.57 1.96 1.65 0.62
19.0°C 2.50 0.55
19.5°C 2.72 1.97 0.51 2.55 1.89 0.55 2.37 1.82 0.59 2.15 1.73 0.63
22.0°C 2.97 2.04 0.52 2.77 1.96 0.56 2.58 1.89 0.60 2.35 1.81 0.64
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TCSHCIPTCSHCIPTCSHCIPTCSHCIP
17.0°C 3.47 2.63 0.83 3.24 2.52 0.89 3.02 2.43 0.95 2.74 2.30 1.03
19.0°C 3.50 0.91
19.5°C 3.81 2.76 0.84 3.56 2.65 0.91 3.31 2.55 0.97 3.01 2.43 1.05
22.0°C 4.15 2.86 0.86 3.88 2.75 0.92 3.61 2.65 0.99 3.28 2.53 1.07
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TCSHCIPTCSHCIPTCSHCIPTCSHCIP
17.0°C 4.17 3.16 1.12 3.89 3.03 1.20 3.62 2.91 1.29 3.29 2.77 1.39
19.0°C 4.20 1.22
19.5°C 4.57 3.31 1.14 4.28 3.18 1.22 3.98 3.06 1.31 3.62 2.91 1.41
22.0°C 4.99 3.43 1.16 4.66 3.30 1.25 4.33 3.18 1.33 3.94 3.03 1.44
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TCSHCIPTCSHCIPTCSHCIPTCSHCIP
17.0°C 4.17 3.16 1.15 3.89 3.03 1.24 3.62 2.91 1.33 3.29 2.77 1.43
19.0°C 4.20 1.26
19.5°C 4.57 3.31 1.18 4.28 3.18 1.27 3.98 3.06 1.35 3.62 2.91 1.46
22.0°C 4.99 3.43 1.20 4.66 3.30 1.29 4.33 3.18 1.38 3.94 3.03 1.49
TC
SHC
IP
-
-
-
Total Cooling Capacity (kW)
Sensible Heat Capacity (kW)
Input Power (kW)
Indoor 27°C/19°C
Outdoor 35°C/24°C
