17
MODEL INDOOR CS-E18LKEW, CS-XE18LKEW CS-E21LKEW, CS-XE21LKEW
OUTDOOR CU-E18LKE CU-E21LKE
Performance Test Condition EUROVENT EUROVENT
Power Supply
Phase, Hz Single, 50 Single, 50
V 230 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.90 5.00 6.00 0.90 6.30 7.10
BTU/h 3070 17100 20500 3070 21500 24200
Kcal/h 770 4300 5160 770 5420 6110
Running Current A — 6.7 — — 9.8 —
Input Power W 215 1.47k 2.03k 215 2.21k 2.54k
Annual Consumption kWh — 735 — — 1105 —
EER
W/W 4.19 3.40 2.96 4.19 2.85 2.80
Kcal/hW 3.58 2.93 2.54 3.58 2.45 2.41
Power Factor % — 95 — — 98 —
Indoor Noise (H / L / QLo)
dB-A 44 / 37 / 34 45 / 37 / 34
Power Level dB 60 / 53 / 50 61 / 53 / 50
Outdoor Noise (H / L)
dB-A 47 / - 48 / -
Power Level dB 61 / - 62 / -
Heating
Capacity
kW 0.90 5.80 8.00 0.90 7.20 8.50
BTU/h 3070 19800 27300 3070 24600 29000
Kcal/h 770 4990 6880 770 6190 7310
Running Current A — 7.0 — — 9.3 —
Input Power W 245 1.54k 2.60k 245 2.10k 2.75k
COP
W/W 3.67 3.77 3.08 3.67 3.43 3.09
Kcal/hW 3.14 3.24 2.65 3.14 2.95 2.66
Power Factor % — 96 — — 98 —
Indoor Noise (H / L / QLo)
dB-A 44 / 37 / 34 45 / 37 / 34
Power Level dB 60 / 53 / 50 61 / 53 / 50
Outdoor Noise (H / L)
dB-A 47 / - 49 / -
Power Level dB 61 / - 63 / -
Low Temp. : Capacity (kW) / I.Power (W) / COP 5.80 / 2.35k / 2.47 6.16 / 2.43k / 2.53
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 4.98 / 2.41k / 2.07 5.24 / 2.54k / 2.06
Max Current (A) / Max Input Power (W) 11.7 / 2.60k 12.1 / 2.75k
Starting Current (A) 7.0 9.8
Compressor
Type Hermetic Motor Hermetic Motor
Motor Type Brushless (4-poles) Brushless (4-poles)
Output Power W 900 900
Indoor Fan
Type Cross-flow Fan Cross-flow Fan
Material ASG30K1 ASG30K1
Motor Type Transistor (8-poles) Transistor (8-poles)
Input Power W — —
Output Power W 40 40
Speed
QLo
Cool rpm 960 960
Heat rpm 1040 1040
Lo
Cool rpm 1040 1050
Heat rpm 1120 1120
Me
Cool rpm 1160 1180
Heat rpm 1240 1290
Hi
Cool rpm 1280 1320
Heat rpm 1360 1460
SHi
Cool rpm 1390 1460
Heat rpm 1430 1480
