Panasonic CS-E7LKEW User Manual

18
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type PWM (8-poles) PWM (8-poles)
Input Power W 74.8 74.8
Output Power W 40 40
Speed Hi
Cool rpm 660 700
Heat rpm 640 680
Moisture Removal L/h (Pt/h) 2.8 (5.9) 3.5 (7.4)
Indoor Airflow
QLo
Cool
m
3
/min (ft
3
/min)
12.00 (424) 12.00 (424)
Heat
m
3
/min (ft
3
/min)
13.20 (466) 13.20 (466)
Lo
Cool
m
3
/min (ft
3
/min)
13.20 (466) 13.30 (470)
Heat
m
3
/min (ft
3
/min)
14.30 (505) 14.30 (505)
Me
Cool
m
3
/min (ft
3
/min)
14.90 (526) 15.10 (533)
Heat
m
3
/min (ft
3
/min)
16.00 (565) 16.20 (572)
Hi
Cool
m
3
/min (ft
3
/min)
16.30 (575) 17.30 (610)
Heat
m
3
/min (ft
3
/min)
17.90 (630) 18.50 (655)
SHi
Cool
m
3
/min (ft
3
/min)
18.10 (639) 19.10 (675)
Heat
m
3
/min (ft
3
/min)
18.50 (653) 19.40 (685)
Outdoor Airflow Hi
Cool
m
3
/min (ft
3
/min)
40.0 (1410) 42.8 (1510)
Heat
m
3
/min (ft
3
/min)
38.6 (1360) 41.5 (1460)
Refrigeration Cycle
Control Device Expansion Valve Expansion Valve
Refrigerant Oil
cm
3
RB68A or Freol Alpha 68M (400) RB68A or Freol Alpha 68M (400)
Refrigerant Type g (oz) R410A, 1.15k (40.6) R410A, 1.29k (45.5)
Dimension Height (I/D / O/D) mm (inch) 290 (11-7/16) / 750 (29-17/32) 290 (11-7/16) / 750 (29-17/32)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) / 875 (34-15/32) 1070 (42-5/32) / 875 (34-15/32)
Depth (I/D / O/D) mm (inch) 235 (9-9/32) / 345 (13-19/32) 235 (9-9/32) / 345 (13-19/32)
Weight Net (I/D / O/D) kg (lb) 12 (26) / 48 (106) 12 (26) / 49 (108)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2) 6.35 (1/4) / 12.70 (1/2)
Standard Length m (ft) 5.0 (16.4) 5.0 (16.4)
Length Range (min - max) m (ft) 3 (9.8) ~ 20 (65.5) 3 (9.8) ~ 20 (65.5)
I/D & O/D Height Different m (ft) 15.0 (49.2) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Length for Additional Gas m (ft) 10.0 (32.8) 10.0 (32.8)
Drain Hose
Inner Diameter mm 16 16
Length mm 650 650
Indoor Heat
Exchanger
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row x Stage x FPI 2 x 15 x 19 2 x 15 x 19
Size (W x H x L) mm 810 x 315 x 25.4 810 x 315 x 25.4
Outdoor Heat
Exchanger
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Corrugated Fin Corrugated Fin
Row x Stage x FPI 2 x 34 x 17 2 x 34 x 18
Size (W x H x L) mm
36.4 x 714 x 794
823
36.4 x 714 x 794
823
Air Filter
Material Polypropelene Polypropelene
Type One-touch One-touch
Power Supply Outdoor Power Supply Outdoor Power Supply
Power Supply Cord A Nil Nil
Thermostat Electronic Control Electronic Control
MODEL INDOOR CS-E18LKEW, CS-XE18LKEW CS-E21LKEW, CS-XE21LKEW
OUTDOOR CU-E18LKE CU-E21LKE
