Panasonic CS-E7NKDW User Manual

137
REF.
NO.
PART NAME & DESCRIPTION QTY. CS-E7NKDW CS-E9NKDW CS-E12NKDW CS-E15NKDW REMARK
1 CHASSIS COMPLETE 1 CWD50C1653 ← ← ←
2 FAN MOTOR 1 ARW7628AC ← ← ← O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1076 ← ← ←
4 BEARING ASS'Y 1 CWH64K007 ← ← ←
5 SCREW - CROSS FLOW FAN 1 CWH551146 ← ← ←
6 GENERATOR COMPLETE 1 CWH94C0043 ← ← ←
7 EVAPORATOR 1 CWB30C2960 CWB30C2755 CWB30C3359 CWB30C3360
8 FLARE NUT (LIQUID) 1 CWT251030 ← ← ←
9 FLARE NUT (GAS) 1 CWT251031 ← ← CWT251032
10 HOLDER SENSOR 1 CWH32143 ← ← ←
11 CONTROL BOARD CASING 1 CWH102449 ← ← ←
12 TERMINAL BOARD COMPLETE 1 CWA28C2357 ← ← ←
13 ELECTRONIC CONTROLLER - MAIN 1 CWA73C6563 CWA73C6564 CWA73C6565 CWA73C6566 O
14 ELECTRONIC CONTROLLER - HVU 1 N0GE1F000002 ← ← ← O
15
ELECTRONIC CONTROLLER -
INDICATOR & RCV
1 CWA746661 ← ← ← O
16 SENSOR COMPLETE 1 CWA50C2401 ← ← ←
17 SENSOR COMPLETE (ECO) 1 CWA50C2820 ← ← ←
18
ELECTRONIC CONTROLLER (ECO
SENSOR)
1 CWA745791 ← ← ← O
20
ELECTRONIC CONTROLLER
(COMPARATOR)
1 CWA746769 ← ← ← O
21 LEAD WIRE - PCB ECO 1 CWA67C9786 ← ← ←
22
CONTROL BOARD CASING FOR PCB
ECO
1 CWD933427 ← ← ←
23 CONTROL BOARD TOP COVER 1 CWH131467 ← ← ←
24 INDICATOR HOLDER 1 CWD933406 ← ← ←
25 CONTROL BOARD FRONT COVER CO. 1 CWH13C1247 ← ← ←
26 DISCHARGE GRILLE COMPLETE 1 CWE20C3236 ← ← ←
27 BACK COVER CHASSIS 1 CWD933233 ← ← ←
28 FULCRUM 1 CWH621131 ← ← ←
29 VERTICAL VANE 8 CWE241374 ← ← ←
30 CONNECTING BAR 2 CWE261251 ← ← ←
33 AIR SWING MOTOR 1 CWA981264 ← ← ← O
34 CAP - DRAIN TRAY 1 CWH521096 ← ← ←
35 HORIZONTAL VANE COMPLETE 1 CWE24C1385 ← ← ←
36 REMOTE CONTROL COMPLETE 1 CWA75C3992 ← ← ← O
37 FRONT GRILLE COMPLETE 1 CWE11C5209 ← ← ← O
38 INTAKE GRILLE COMPLETE 1 CWE22C1723 ← ← ← O
39 GRILLE DOOR COMPLETE 1 CWE14C1090 ← ← ←
40 AIR FILTER 2 CWD001279 ← ← ←
41 SCREW - FRONT GRILLE 2 XTT4+16CFJ ← ← ←
42 CAP - FRONT GRILLE 2 CWH521227 ← ← ←
43 DRAIN HOSE 1 CWH851173 ← ← ←
44 INSTALLATION PLATE 1 CWH361097 ← ← ←
45
BAG COMPLETE - INSTALLATION
SCREW
1 CWH82C1705 ← ← ←
46 OPERATING INSTRUCTION 1 CWF568372 ← ← ←
47 INSTALLATION INSTRUCTION 1 CWF615101 ← ← ←
48 INSTALLATION INSTRUCTION 1 CWF615102 ← ← ←
49 INSTALLATION INSTRUCTION 1 CWF615103 ← ← ←
