143
REF.
NO.
DESCRIPTION & NAME QTY CU-E7NKD CU-E9NKD CU-E12NKD CU-E15NKD REMARK
1 CHASSIS ASS’Y 1 CWD50K2073 ← ← ←
2 SOUND PROOF MATERIAL 1 CWG302447 CWG302292 ← ←
3 FAN MOTOR BRACKET 1 CWD541089 ← ← ←
4 SCREW - FAN MOTOR BRACKET 2 CWH551217 ← ← ←
5 FAN MOTOR 1 CWA951720 CWA951721 CWA951699 CWA951722 O
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J ← ← ←
7 PROPELLER FAN ASS’Y 1 CWH03K1010 ← ← ←
8 NUT - PROPELLER FAN 1 CWH56053J ← ← ←
9 COMPRESSOR 1 5RS092XCD21 5RS102XBC21 ← ←
10 ANTI - VIBRATION BUSHING 3 CWH50077 ← ← ←
11 NUT - COMPRESSOR MOUNT 3 CWH56000J ← ← ←
12 CONDENSER 1 CWB32C3191 CWB32C2815 ← ←
13 TUBE ASSY (CAP, CHECK VALVE) 1 CWT01C5305 CWT01C4850 CWT01C4851 CWT01C4852
14 DISCHARGE MUFFLER 1 CWB121010 ← ← ←
15 HOLDER - COUPLING 1 CWH351023 ← ← ←
16 2-WAYS VALVE (LIQUID) 1 CWB021559 CWB021457 ← ← O
17 3-WAYS VALVE (GAS) 1 CWB011374 ← ← CWB011367 O
19 REACTOR 1 G0C193J00002 ← G0C193J00004 ←
20 TERMINAL COVER 1 CWH171039A ← ← ←
21 NUT – TERMINAL COVER 1 CWH7080300J ← ← ←
22 SOUND PROOF BOARD 1 CWH151172 ← ← ←
23A SOUND PROOF MATERIAL 1 CWG302443 CWG302293 ← ←
24
SENSOR CO. (OUTDOOR
COMPRESSOR TEMP)
1 CWA50C2205 ← ← ← O
25 CONTROL BOARD COVER (TOP) 1 CWH131264 ← ← ←
26
ELECTRONIC CONTROLLER -
MAIN
1 CWA73C6570R CWA73C6571R CWA73C6572R CWA73C6573R O
27 TERMINAL BOARD ASSY 1 CWA28K1110J ← ← ←
28 CABINET SIDE PLATE (R) 1 CWE04C1116 ← ← ←
29
SENSOR CO. (OUTDOOR AIR
AND HEAT EXCHANGE TEMP)
1 CWA50C2764 ← ← ← O
30 CABINET SIDE PLATE (L) 1 CWE041248A ← ← ←
31 CABINET FRONT PLATE CO. 1 CWE06C1039 ← ← ←
32 CABINET TOP PLATE 1 CWE031014A ← ← ←
33 PLATE-C.B.COVER 1 CWH131301 ← ← ←
34
CONTROL BOARD COVER
COMPLETE
1 CWH13C1211 ← ← ←
35 HANDLE 1 CWE161010 ← ← ←
38 4-WAYS VALVE 1 CWB001037J ← ← ←
39 V-COIL COMPLETE 1 CWA43C2431 ← ← ←
40 WIRE NET 1 CWD041111A ← ← ←
41
ACCESSORY CO. (DRAIN
ELBOW)
1 CWG87C900 ← ← ←
45 BAG 1 CWG861078 ← ← ←
46 BASE BOARD-COMPLETE 1 CWG62C1095 ← ← ←
47 SHOCK ABSORBER (R) 1 CWG712969 ← ← ←
48 SHOCK ABSORBER (L) 1 CWG712970 ← ← ←
49 C.C. CASE 1 CWG567624 CWG567625 CWG567626 CWG567706
(NOTE)
All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
“O” marked parts are recommended to be kept in stock.
To Next Page
