17.2 Sensible Capacity Chart
• CU-E9PKEA
230V Outdoor Temperature
30 °C 35 °C 40 °C 46 °C
Indoor
wet bulb
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0 °C 2.48 1.88 0.47 2.32 1.80 0.51 2.16 1.73 0.54 1.96 1.65 0.59
19.0 °C 2.50 0.52
19.5 °C 2.72 1.97 0.48 2.55 1.89 0.52 2.37 1.82 0.55 2.15 1.73 0.60
22.0 °C 2.97 2.04 0.49 2.77 1.96 0.53 2.58 1.89 0.56 2.35 1.81 0.61
• CU-E12PKEA
230V Outdoor Temperature
30 °C 35 °C 40 °C 46 °C
Indoor
wet bulb
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0 °C 3.47 2.63 0.80 3.24 2.52 0.86 3.02 2.43 0.92 2.74 2.30 0.99
19.0 °C 3.50 0.87
19.5 °C 3.81 2.76 0.81 3.56 2.65 0.87 3.31 2.55 0.93 3.01 2.43 1.01
22.0 °C 4.15 2.86 0.83 3.88 2.75 0.89 3.61 2.65 0.95 3.28 2.53 1.03
• CU-E15PKEA
230V Outdoor Temperature
30 °C 35 °C 40 °C 46 °C
Indoor
wet bulb
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0 °C 4.17 3.16 1.10 3.89 3.03 1.18 3.62 2.91 1.26 3.29 2.77 1.36
19.0 °C 4.20 1.20
19.5 °C 4.57 3.31 1.12 4.28 3.18 1.20 3.98 3.06 1.29 3.62 2.91 1.39
22.0 °C 4.99 3.43 1.14 4.66 3.30 1.23 4.33 3.18 1.31 3.94 3.03 1.41
• CU-E18PKEA
230V Outdoor Temperature
30 °C 35 °C 40 °C 46 °C
Indoor
wet bulb
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0 °C 4.96 3.76 1.32 4.64 3.61 1.42 4.31 3.47 1.52 3.92 3.29 1.64
19.0 °C 5.00 1.44
19.5 °C 5.45 3.94 1.34 5.09 3.78 1.45 4.74 3.64 1.55 4.31 3.47 1.67
22.0 °C 5.94 4.08 1.37 5.55 3.93 1.47 5.16 3.79 1.57 4.69 3.61 1.70
