Panasonic CS-E9PKEA - Cu-E15 Pkea Cu-E18 Pkea

20
6.2 CU-E15PKEA CU-E18PKEA
INDOOR OUTDOOR
INTAKE
AIR
TEMP.
SENSOR
PIPE
TEMP.
SENSOR
PIPE
TEMP.
SENSOR
AIR
TEMP.
SENSOR
LIQUID
SIDE
2-WAY
VALVE
3-WAY
VALVE
GAS
SIDE
COOLING
HEAT EXCHANGER
(EVAPORATOR)
HEATING
COMPRESSOR
CONDENSER
PROCESS
TUBE
STRAINER
EXPANSION
VALVE
4-WAYS VALVE
TANK
SENSOR
DIS. TEMP.
SENSOR
