121
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CS-E18PKEA REMARK
1 CHASSIS COMPLETE 1 CWD50C1742
2 FAN MOTOR 1 ARW7676ACCB O
3 CROSS - FLOW FAN COMPLETE 1 CWH02C1136
4 BEARING ASSY 1 CWH64K1010
5 SCREW - CROSS - FLOW FAN 1 CWH551146
6 EVAPORATOR 1 CWB30C4217
7 FLARE NUT (LIQUID) 1 CWT251030
8 FLARE NUT (GAS) 1 CWT251032
9 CLIP FOR SENSOR 1 CWH711019
10 BACK COVER CHASSIS 1 CWD933463
11 DISCHARGE GRILLE COMPLETE 1 CWE20C3378
12 VERTICAL VANE 8 CWE241389
13 VERTICAL VANE (MAIN) 2 CWE241409
14 CONNECTING BAR (RIGHT) 1 CWE261269
14a CONNECTING BAR (MIDDLE) 1 CWE261268
15 CONNECTING BAR (LEFT) 1 CWE261267
18 FULCRUM 1 CWH621150
19 HORIZONTAL VANE COMPLETE 1 CWE24C1433
20 HORIZONTAL VANE COMPLETE 1 CWE24C1434
21 AIR SWING MOTOR 1 CWA981304 O
22 AIR SWING MOTOR 1 CWA981299 O
23 CAP - DRAIN TRAY 1 CWH521259
24 SENSOR COMPLETE 1 CWA50C2663 O
25 ELECTRONIC CONTROLLER - MAIN 1 CWA73C7163 O
27 CONTROL BOARD CASING 1 CWH102456
28 CONTROL BOARD TOP COVER 1 CWH131531
29 CONTROL BOARD FRONT COVER CO. 1 CWH13C1286
30 TERMINAL BOARD COMPLETE 1 CWA28C2608 O
31 ELECTRONIC CONTROLLER - INDICATOR 1 CWA747322 O
32 INDICATOR HOLDER 1 CWD933466
33 FRONT GRILLE COMPLETE 1 CWE11C5443
34 GRILLE DOOR COMPLETE 1 CWE14C1099
35 INTAKE GRILLE COMPLETE 1 CWE22K1613
36 DECORATION BASE (LEFT) 1 CWE351341
37 DECORATION BASE (RIGHT) 1 CWE351326
38 SCREW - FRONT GRILLE 3 XTT4+16CFJ
39 AIR FILTER 2 CWD001338
40 DRAIN HOSE 1 CWH851173
41 REMOTE CONTROL CO. (WIRED) 1 CWA75C3375 O
42 INSTALLATION PLATE 1 CWH361098
43 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1942
44 OPERATING INSTRUCTION 1 CWF568897
45 INSTALLATION INSTRUCTION 1 CWF615627
46 INSTALLATION INSTRUCTION 1 CWF615628
47 INSTALLATION INSTRUCTION 1 CWF615629
48 INSTALLATION INSTRUCTION 1 CWF615630
49 INSTALLATION INSTRUCTION 1 CWF615631
50 INSTALLATION INSTRUCTION 1 CWF615632
51 INSTALLATION INSTRUCTION 1 CWF615633
52 INSTALLATION INSTRUCTION 1 CWF615634
To Next Page
