8
Indoor CS-E12PKEA CS-E15PKEA
Model
Outdoor CU-E12PKEA CU-E15PKEA
Performance Test Condition EUROVENT EUROVENT
Phase, Hz Single, 50 Single, 50
Power Supply
V 230 230
Min. Mid. Max. Min. Mid. Max.
kW 0.85 3.50 4.00 0.98 4.20 5.00
BTU/h 2900 11900 13600 3340 14300 17100
Capacity
Kcal/h 730 3010 3440 840 3610 4300
Running Current A – 3.8 – – 5.4 –
Input Power W 170 870 1.12k 280 1.20k 1.58k
Annual Consumption kWh - 435 – – 600 –
W/W 5.00 4.02 3.57 3.50 3.50 3.16
BTU/hW 17.06 13.68 12.14 11.93 11.92 10.82
EER
Kcal/hW 4.29 3.46 3.07 3.00 3.01 2.72
Pdesign kW 3.5 4.2
SEER (W/W) 6.7 6.3
Annual
Consumption
kWh 183 233
ErP
Class A++ A++
Power Factor % – 95 – – 97 –
dB-A 42 / 29 / 26 43 / 32 / 29
Indoor Noise (H / L / QLo)
Power Level dB 58 / – 59 / –
dB-A 48 / – 46 / –
Cooling
Outdoor Noise (H / L)
Power Level dB 63 / – 61 / –
kW 0.85 4.00 6.60 0.98 5.40 7.10
BTU/h 2900 13600 22500 3340 18400 24200
Capacity
Kcal/h 730 3440 5680 840 4640 6110
Running Current A – 4.2 – – 6.5 –
Input Power W 165 920 1.82k 340 1.44k 2.19k
W/W 5.15 4.35 3.63 2.88 3.75 3.24
BTU/hW 17.58 14.78 12.36 9.82 12.78 11.05
COP
Kcal/hW 4.42 3.74 3.12 2.47 3.22 2.79
Pdesign kW 3.6 3.6
Tbivalent °C -10 -10
SCOP (W/W) 4.1 3.9
Annual
Consumption
kWh 1229 1292
ErP
Class A+ A
Power Factor % – 95 – – 96 –
dB-A 42 / 33 / 30 43 / 35 / 29
Indoor Noise (H / L / QLo)
Power Level dB 58 / – 59 / –
dB-A 50 / – 46 / –
Heating
Outdoor Noise (H / L)
Power Level dB 65 / – 61 / –
Low Temp. : Capacity (kW) / I.Power (W) / COP 4.78 / 1.61k / 2.97 5.14 / 1.94k / 2.65
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 4.07 / 1.70k / 2.39 4.10 / 2.08k / 1.97
Max Current (A) / Max Input Power (W) 8.4 / 1.85k 9.6 / 2.19k
Starting Current (A) 4.2 6.5
