Panasonic CS-F28DB4E5 Service Manual

123
HC: Heating Capacity IPT: Heating Power Consumption
Model Heating capacities are based on conditions
CS-F28DB4E5 Single phase, 50Hz 230V, Three phase, 50Hz 400V
Heating capacity Indoor temp. 20°C D.B.
8kW Outdoor temp. 7°C D.B. 6°C W.B.
Standard air volume 20 m
3
/min
Ambient Temperature Air Entering Condenser (°C D.B.)
Return -6°C0°C6°C12°C
Air HCHCHCHC
D.B. kW kW kW kW
15 5.84 7.00 8.40 9.76
20 5.52 6.60 8.00 9.60
25 5.20 6.24 7.60 9.20
Ambient Temperature Air Entering Condenser (°C D.B.)
Return -6°C0°C6°C12°C
Air IPT IPT IPT IPT
D.B. kW kW kW kW
15 1.82 2.08 2.47 2.91
20 1.92 2.21 2.60 3.02
25 2.03 2.34 2.73 3.05
