Panasonic CS-F28DB4E5 Service Manual

145
15.2. CS-F34DB4E5 CS-F43DB4E5 CS-F50DB4E5
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
REF. NO. PART NAME & DESCRIPTION QTY. CS-F34DB4E5 CS-F43DB4E5 CS-F50DB4E5
1 BASE PAN ASS’Y 1 CWD52K1099 ←←
2 INNER POLYSTYRENE COMPLETE 1 CWG07C1048 ←←
3 CABINET SIDE PLATE ASS’Y 1 CWB30C1135 ←←
4 CABINET SIDE PLATE ASS’Y 1 CWB30C1136 ←←
6 FAN MOTOR 1 EHDS50A60AC ←←
7 ANTI-VIBRATION BUSHING 4 CWH501065 ←←
9 SCREW-FAN MOTOR 4 CWH7080300 ←←
11 TURBO FAN 1 CWH03K1023 ←←
12 NUT for TURBO FAN 1 CWH561042 ←←
13 SP WASHER 1 XWA8 ←←
14 WASHER 1 XWG8H22 ←←
15 EVAPORATOR COMPLETE 1 CWB30C1553 ← CWB30C1753
16 FLARE NUT (5/8”) 1 CWT251016 ← CWT251033
17 HEATPROOF TUBE 1 CWG251035 ←←
18 HEATPROOF TUBE 1 CWG251021 ←←
19 FLARE NUT (3/8”) 1 CWT25087 ← CWT251031
21 PIPE COVER 1 CWD93C1047 ←←
22 SENSOR-EVAPORATOR 1 CWA50C2216 ←←
23 HOLDER SENSOR 1 CWH321044 ←←
24 EVAPORATOR SUPPORTER 1 CWD911468A ← ¨
25 TUBE ASS’Y (CAPIL. TUBE) 1 CWT07K1198 ← CWT07K1274
26 DRAIN PUMP COMPLETE 1 CWB53C1014 ←←
27 PANEL DRAIN PUMP ASS’Y 1 CWD93K1007 ←←
28 DRAIN PUMP 1 CWB532043 ←←
29 ANTI-VIBRATION BUSHING 3 CWH501080 ←←
30 FLOAT SWITCH-DRAIN PUMP 1 CWA121215 ←←
31 FLEXIBLE PIPE 1 CWH851030 ←←
32 DRAIN NOZZLE 1 CWH411013 ←←
33 DRAIN HOSE HEAT INSULATION 1 CWG101025 ←←
35 DRAIN PAN-COMPLETE 1 CWH40C1033 ←←
36 DRAIN PLUG 1 CWB821008 ←←
37 AIR GUIDER BLOWER WHEEL 1 CWD321059 ←←
38 CONTROL BOARD CASING 1 CWH10K1047 ←←
39 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C1691 CWA73C1692 CWA73C1693
40 SPACER 6 CWH541026 ←←
41 CAPACITOR FAN MOTOR 1 G0A203H00001 ←←
42 TERMINAL BOARD ASS’Y 1 CWA28K1112 ←←
43 TERMINAL BOARD ASS’Y 1 CWA28K1076 ←←
44 LEADWIRE-AIR TEMP. SENSOR 1 CWA67C5139 ←←
47 CONTROL BOARD COVER COMPLETE 1 CWH13C1116 ←←
48 ACCESSORY COMPLETE 1 CWH82C1270 ←←
48a HEATPROOF TUBE 1 CWG021025 ←←
49 WIRED REMOTE CONTROL COMPLETE (ACCES-
SORY)
1 CWG50C2604 ←←
50 WIRED REMOTE CONTROL COMPLETE 1 CWA75C2586 ←←
51 WIRELESS REMOTE CONTROL COMPLETE 1 CWA75C2588 ←←
52 RAY RECEIVER COMPLETE 1 CWD91C0038 ←←
100 CORD HOLDER 1 CWD741020 ←←
OPERATING INSTRUCTION 1 CWF564539
← CWF564624
INSTALLATION INSTRUCTION 1 CWF612614 ←←
OPERATING INSTRUCTION 1 CWF564536 ← CWF564625
OPERATING INSTRUCTION 1 CWF564537 ← CWF564626
OPERATING INSTRUCTION 1 CWF564538 ← CWF564627
OPERATING INSTRUCTION 1 - ← CWF564876
