126
HC: Heating Capacity IPT: Heating Power Consumption
Model Heating capacities are based on conditions
CS-F43DB4E5 3 phase, 50Hz 400V
Heating capacity Indoor temp. 20°C D.B.
14.0kW Outdoor temp. 7°C D.B. 6°C W.B.
Standard air volume 31 m
3
/min
Ambient Temperature Air Entering Condenser (°C D.B.)
Return -6°C0°C6°C12°C
Air HCHCHCHC
D.B. kW kW kW kW
15 10.22 12.25 14.70 17.08
20 9.66 11.55 14.00 16.80
25 9.10 10.92 13.30 16.10
Ambient Temperature Air Entering Condenser (°C D.B.)
Return -6°C0°C6°C12°C
Air IPT IPT IPT IPT
D.B. kW kW kW kW
15 3.28 3.75 4.46 5.25
20 3.47 3.99 4.69 5.44
25 3.66 4.22 4.92 5.56
