Panasonic CS-F34DB4E5

144
15 Replacement Part List (Indoor Unit)
15.1. CS-F24DB4E5 CS-F28DB4E5
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
REF. NO. PART NAME & DESCRIPTION QTY. CS-F24DB4E5 CS-F28DB4E5
1 BASE PAN ASS’Y 1 CWD52K1099 ←
2 INNER POLYSTYRENE COMPLETE 1 CWG07C1045 ←
3 CABINET SIDE PLATE ASS’Y 1 CWE041112 ←
4 CABINET SIDE PLATE ASS’Y 1 CWE041113 ←
6 FAN MOTOR 1 EHDS50A40AC ←
7 ANTI-VIBRATION BUSHING 3 CWH501065 ←
9 SCREW-FAN MOTOR 3 CWH7080300 ←
11 TURBO FAN 1 CWH03K1021 ←
12 NUT for TURBO FAN 1 CWH561042 ←
13 SP WASHER 1 XWA8 ←
14 WASHER 1 XWG8H22 ←
15 EVAPORATOR COMPLETE 1 CWB30C1514 ←
16 FLARE NUT (5/8”) 1 CWT251016 ←
17 HEATPROOF TUBE 1 CWG251035 ←
18 HEATPROOF TUBE 1 CWG251021 ←
19 FLARE NUT (3/8”) 1 CWT25087 ←
21 PIPE COVER 1 CWD93C1047 ←
22 SENSOR-EVAPORATOR 1 CWA50C2216 ←
23 HOLDER SENSOR 1 CWH321044 ←
24 EVAPORATOR SUPPORTER 1 CWD911404A ←
25 TUBE ASS’Y (CAPIL. TUBE) 1 CWT07K1183 ←
26 DRAIN PUMP COMPLETE 1 CWB53C1014 ←
27 PANEL DRAIN PUMP ASS’Y 1 CWD93K1007 ←
28 DRAIN PUMP 1 CWB532043 ←
29 ANTI-VIBRATION BUSHING 3 CWH501080 ←
30 FLOAT SWITCH-DRAIN PUMP 1 CWA121215 ←
31 FLEXIBLE PIPE 1 CWH851030 ←
32 DRAIN NOZZLE 1 CWH411013 ←
33 DRAIN HOSE HEAT INSULATION 1 CWG101025 ←
35 DRAIN PAN-COMPLETE 1 CWH40C1033 ←
36 DRAIN PLUG 1 CWB821008 ←
37 AIR GUIDER BLOWER WHEEL 1 CWD321057 ←
38 CONTROL BOARD CASING 1 CWH10K1047 ←
39 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C1689 CWA73C1690
40 SPACER 6 CWH541026 ←
41 CAPACITOR FAN MOTOR 1 G0A203H00001 ←
42 TERMINAL BOARD ASS’Y 1 CWA28K1112 ←
43 TERMINAL BOARD ASS’Y 1 CWA28K1076 ←
44 LEADWIRE-AIR TEMP. SENSOR 1 CWA67C5139 ←
47 CONTROL BOARD COVER COMPLETE 1 CWH13C1097 ←
48 ACCESSORY COMPLETE 1 CWH82C1270 ←
48a HEATPROOF TUBE 1 CWG021025 ←
49 WIRED REMOTE CONTROL COMPLETE (ACCESSORY) 1 CWG50C2604 ←
50 WIRED REMOTE CONTROL COMPLETE 1 CWA75C2586 ←
51 WIRELESS REMOTE CONTROL COMPLETE 1 CWA75C2588 ←
52 RAY RECEIVER COMPLETE 1 CWD91C0038 ←
100 CORD HOLDER 1 CWD741020 ←
OPERATING INSTRUCTION 1 CWF564508 ←
INSTALLATION INSTRUCTION 1 CWF612614 ←
OPERATING INSTRUCTION 1 CWF564397 ←
OPERATING INSTRUCTION 1 CWF564398 ←
OPERATING INSTRUCTION 1 CWF564399 ←
OPERATING INSTRUCTION 1 - ←
