19 Replacement Part List (Outdoor Unit)
19.1. CU-B24DBE5 CU-B28DBE5 CU-B28DBE8
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
NO. PART DESCRIPTION QTY. CU-B24DBE5 CU-B28DBE5 CU-B28DBE8
1 BASE PAN ASS’Y 1 CWD52K1102 ←←
2 COMPRESSOR 1 5JS315DAM21 5JS330DAF21 5JS330PBA21
3 ANTI-VIBRATION BUSHING 3 CWH50055 ←←
4 NUT FOR COMP. MOUNT. 3 CWH561049 ←←
5 PACKING 3 CWB811017 ←←
6 CRANKCASE HEATER 1 CWA341017 ←←
7 CONDENSER COMPLETE 1 CWB32C1706 CWB32C1716 ←
8 TUBE ASS’Y(CAPILLARY TUBE) 1 CWT07K1306 CWT07K1302 ←
9 PIPE HOLDER RUBBER 1 CWG251016 ←←
10 4-WAYS VALVE COMPLETE 1 CWB00C1031 ←←
11 DISCHARGE MUFFLER 1 CWB121013 ←←
12 4-WAYS VALVE 1 CWB001026J ←←
13 HEATING PRESSURE SWITCH 1 CWA101007 ←←
14 TUBE ASS’Y(EXP.VALVE AND STRAINER) 1 CWT024068 CWT024146 ←
15 3-WAYS VALVE(LIQUID) 1 CWB011252 ←←
16 3-WAYS VALVE(GAS) 1 CWB011251 ←←
17 TUBE RECEIVER 1 CWB141031 ←←
18 STRAINER 2 CWB111032 ←←
19 PIPE HOLDER RUBBER 1 CWG251016 ←←
20 HOLDER-SERVICE VALVE 1 CWD911425 ←←
21 SOUND-PROOF BOARD ASS’Y 1 CWH151078 ←←
22 TUBE RECEIVER 1 CWB14K1014A ←←
23 SOUND PROOF MATERIAL-COMP 1 CWG302338 ←←
24 V-COIL COMPLETE 1 CWA43C2169 ←←
25 V-COIL COMPLETE 1 CWA43C2128J ←←
26 PIPE SENSOR 1 CWA50C2292 ←←
27 PIPE SENSOR 1 CWA50C2293 ←←
28 SPRING FOR SENSOR 2 CWH711010 ←←
29 CABINET REAR PLATE COMPLETE 1 CWE02C1029 ←←
30 CONTROL BOARD ASS’Y 1 CWH10K1063 ← CWH10K1064
31 TERMINAL BOARD ASS’Y 1 CWA28K1085J ← CWA28K1109
32 TERMINAL BOARD ASS’Y 1 CWA28K1076J ←←
33 CAPACITOR-FAN MOTOR (3/460) (3.5/460) 1 DS461305QP-A DS461355QP-A ←
34 CAPACITOR-COMP. (45/370) (50/370) 1 DS371456CPNA DS371506CPNA -
35 HOLDER CAPACITOR 1 CWH30060 CWH30060 -
36 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C1902 CWA73C1904 CWA73C1905
37 MAGNETIC RELAY 1 K6C2A9A00001 ← -
38 TRANSFORMER 1 CWA401060 ←←
39 TERMINAL COVER 1 CWH171012 ← CWH171015
40 NUT FOR TERMINAL COVER 1 CWH7080300J ←←
41 BRACKET FAN MOTOR ASS’Y 1 CWD54K1010 ←←
42 SCREW-BRACKET FAN MOTOR 2 CWH551040J ←←
43 FAN MOTOR AC 70W SINGLE 1 CWA951366 ←←
44 SCREW-BRACKET FAN MOTOR 4 CWH551040J ←←
45 PROPELLER FAN 1 CWH001019 ←←
46 NUT for PROPELLER FAN 1 CWH561038J ←←
47 CABINET TOP PLATE COMPLETE 1 CWE03C1039 ←←
48 PIPE COVER (FRONT) 1 CWD601074A ←←
49 PIPE COVER (BACK) 1 CWD601081A ←←
50 CABINET FRONT PLATE 1 CWE061118A ←←
51 DISCHARGE GRILLE 1 CWE201073 ←←
52 CABINET SIDE PLATE ASS’Y 1 CWE04K1019A ←←
53 WIRE NET 1 CWD041063A ←←
54 CABINET FRONT PLATE COMPLETE 1 CWE06C1147 ←←
55 HANDLE 3 CWE161008 ←←
56 LEADWIRE-COMPRESSOR 1 CWA67C5994 ← CWA67C5909
57 WIRINF COVER AND BAND 1 CWH82C1105 ←←
58 INSTALLATION INSTRUCTION 1 CWF612864 ←←
59 ACCESSORY COMPLETE (DRAIN ELBOW) 1 CWG82C2030 ←←
60 ELECTRO MAGNETIC SWITCH 1 - - K6C4E8A00003
