Panasonic CS-F50DTE5 Simplified Service Manual

21
8.2. Capacity And Power Consumption
8.2.1. Cooling performance
Calculation of actual cooling capacity and power consumption:
Example: CS-F24DTE5 / CU-L24DBE5
• Calculation of the actual cooling capacity and power consumption for the following cooling conditions;
Indoor temperature of 27/19°C and outdoor temperature of 40°C (Standard condition).
Calculation method
1. Find the cooling capacity ratio and the power consumption ratio from the cooling capacity graph and power consumption graph for model CS-
F24DTE5 / CU-L24DBE5.
• The cooling capacity ratio indicate at the intersection between an outdoor unit air inlet temperature of 40°C on the horizontal axis and an
indoor unit air inlet temperature on 27/19°C is 0.95.
• The cooling power consumption ratio from the same intersection on the power consumption graph is 1.03.
2. Thus,
• Actual cooling capacity = cooling capacity ratio x rated cooling capacity = 0.95 x 6.5 = 6.18 (kw).
• Actual cooling power consumption = cooling power consumption x rated power consumption = 1.03 x 2.45 = 2.52 (kw).
Model name Max cooling capacity
Max capacity (kw) Max power consumption (kw)
CS-F24DTE5 / CU-L24DBE5 6.5 2.3
CS-F28DTE5 / CU-L28DBE5 7.5 2.45
CS-F34DTE5 / CU-L34DBE5 12 3.4
CS-F43DTE5 / CU-L43DBE5 13.5 4.3
CS-F50DTE5 / CU-L50DBE5 16 5.1

Panasonic CS-F50DTE5 Specifications

General

Indoor unit type	Ceiling
Indoor unit weight	47000 g
Indoor units quantity	1
Indoor unit dimensions (WxDxH)	1600 x 700 x 250 mm
Indoor unit noise level (high speed)	50 dB
Outdoor unit weight	105000 g
Outdoor unit noise level	56 dB
Outdoor unit dimensions (WxDxH)	900 x 320 x 1340 mm
Hose length (max)	50 m
Inverter technology	Yes
Refrigerating medium	R410A
Cooling capacity (max)	47700 BTU/h
Heating capacity (max)	54600 BTU/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	14000 W
Heating capacity in watts (max)	16000 W
Cooling energy efficiency (EER, W/W)	2.91
Heating energy efficiency (COP, W/W)	3.41
