Panasonic CS-F50DTE5 Simplified Service Manual

29
8.4. Operating characteristics
Model Main Power
Source
Compressor Motor Indoor Unit
Fan Motor
Outdoor Unit
Fan Motor
Voltage Frequency S.C. R.C. (A) IPT (kW) R.C. IPT R.C. IPT
(V) (Hz) (A) COOL / HEAT COOL / HEAT (A) (kW) (A) (kW)
H
E
A
T
P
U
M
P
M
O
D
E
L
CS-F24DTE5
CU-L24DBE5
220 50 9.9 7.28 / 7.98 1.55 / 1.69 0.17 0.03 0.55 0.12
230 50 9.5 6.98 / 7.68 1.55 / 1.69 0.17 0.03 0.55 0.12
240 50 9.2 6.78 / 7.38 1.55 / 1.69 0.17 0.03 0.55 0.12
CS-F28DTE5
CU-L28DBE5
220 50 11.1 8.8 / 9.2 1.85 / 1.96 0.20 0.035 0.55 0.12
230 50 10.7 8.5 / 8.9 1.85 / 1.96 0.20 0.035 0.55 0.12
240 50 10.3 8.1 / 8.5 1.85 / 1.96 0.20 0.035 0.55 0.12
CS-F34DTE5
CU-L34DBE5
220 50 14.4 10.7 / 12.2 2.29 / 2.60 0.35 0.07 1.10 0.24
230 50 13.9 10.3 / 11.8 2.29 / 2.60 0.35 0.07 1.10 0.24
240 50 13.5 10.0 / 11.3 2.29 / 2.60 0.35 0.07 1.10 0.24
CS-F43DTE5
CU-L43DBE5
220 50 19.5 15.5 / 16.6 3.31 / 3.55 0.45 0.09 1.10 0.24
230 50 18.8 15.0 / 16.1 3.31 / 3.55 0.45 0.09 1.10 0.24
240 50 18.2 14.5 / 15.6 3.31 / 3.55 0.45 0.09 1.10 0.24
CS-F50DTE5
CU-L50DBE5
220 -- - - ----
230 -- - - ----
240 50 20.8 19.14 / 19.54 4.31 / 4.41 2.67 0.10 1.10 0.24
Legend : S.C. : Starting Current
R.C. : Running Current
IPT : Power Consumption

Panasonic CS-F50DTE5 Specifications

General

Indoor unit type	Ceiling
Indoor unit weight	47000 g
Indoor units quantity	1
Indoor unit dimensions (WxDxH)	1600 x 700 x 250 mm
Indoor unit noise level (high speed)	50 dB
Outdoor unit weight	105000 g
Outdoor unit noise level	56 dB
Outdoor unit dimensions (WxDxH)	900 x 320 x 1340 mm
Hose length (max)	50 m
Inverter technology	Yes
Refrigerating medium	R410A
Cooling capacity (max)	47700 BTU/h
Heating capacity (max)	54600 BTU/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	14000 W
Heating capacity in watts (max)	16000 W
Cooling energy efficiency (EER, W/W)	2.91
Heating energy efficiency (COP, W/W)	3.41
