Panasonic CS-LE9NKD - Automatic Operation Logic; Indoor Fan Motor Operation

27
12.1.5 Automatic Operation
• Once AUTO mode is selected, operation mode is determined by set temperature of remote control and indoor
intake temperature.
1
st
judgment
JUDGE CONDITION REFERANCE MODE
If indoor intake temp – Remote control
temp setting ≥ +2
Cool mode
If -2 ≤ indoor intake temp. – Remote
control Temp. setting ≤ +2
Dry mode
If indoor intake temp. – Remote control
temp. setting < -2
Heat mode
2
nd
& following judgment (every 10 minutes after 1
st
judgment)
JUDGE CONDITION REFERANCE MODE
If indoor intake temp – Remote control temp
setting ≥ +3
 Cool mode if previously is Cool /
Heat mode
 Dry mode if previously is Dry mode
If -2 ≤ indoor intake temp. –
Remote control
Temp. setting < +3
Maintain current mode
If indoor intake temp. – Remote control
temp. setting < -2
Heat mode
Note:
• When auto judgment has been made to operate in Cool mode, the unit will enter different states according to
outdoor temperature conditions:-
Outdoor Temp. Condition Air Conditioner Status
If outdoor temperature≥ 16℃
Cooling operation
If outdoor temperature <16℃
Compressor OFF and standby.
• During sampling and making judgment, POWER LED will blink.
• When judgment has been made, POWER LED will stop blinking and ON.
• During AUTO mode operation, horizontal louver direction and FAN speed can be selected by remote control
12.2 Indoor Fan Motor Operation
A. Basic Rotation Speed
i. Manual Fan speed
Fan motor’s number of rotation is determined according to remote control setting.
Intake temp.- setting temp.
DRY
COOL
HEAT
-6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6
MAINTAIN
CURRENT MODE
COOL/DRY
HEAT
Intake temp.- setting temp.
-6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6
