6
Hi m
3
/min (ft
3
/m) 12.0 (424) 13.3 (470)
Q-Lo m
3
/min (ft
3
/m) 6.8 (239) 8.0 (283)
Lo m
3
/min (ft
3
/m) 7.9 (279) 9.7 (344)
Me m
3
/min (ft
3
/m) 9.2 (326) 11.1 (392)
Indoor Airflow
(HEATING)
Hi m
3
/min (ft
3
/m) 11.5 (406) 12.6 (445)
Hi (Cooling) m
3
/min (ft
3
/m) 32.9 (1162) 36.8 (1300)
Outdoor Airflow
Hi (Heating) m
3
/min (ft
3
/m) 32.9 (1162) 36.8 (1300)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
FV50S (250) FV50S (320)
Refrigeration
Cycle
Refrigerant Type
g (oz) R410A, 640 (22.6) R410A, 690 (24.4)
Height(I/D / O/D)
mm (inch) 283 (11-15/32)
530 (20-55/64)
283 (11-5/32)
624 (24-37/64)
Width (I/D / O/D)
mm (inch) 803 (31-5/8)
720 (28-11/32)
803 (31-5/8)
780 (30-45/64)
Dimension
Depth (I/D / O/D)
mm (inch) 216 (8-1/2) 275 (10-53/64)
216 (8-1/2) 289 (11-3/8)
Weight Net (I/D / O/D) kg (lb) 8.5 (19) 20 (44) 8.5 (19) 24 (53)
Pipe Diameter
(Liquid / Gas)
mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 9.52 (3/8)
Standard length m (ft) 5 (16.4) 5 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 5.0 (16.4) 5.0 (16.4)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.0 (23.0) 7.0 (23.0)
Inner diameter mm 16 16 Drain Hose
Length mm 500 500
Fin Material Pre coated Pre coated
Fin Type Slit Fin Slit Fin
Row x Stage x FPI 2 x 16 x 19 2 x 16 x 19
Indoor
Heat
Exchanger
Size (W x H x L) mm 610 x 336 x 25.4 610 x 336 x 25.4
Fin Material Pre coated Pre coated
Fin Type Slit Fin Slit Fin
Row x Stage x FPI 1 x 24 x 19 1 x 28 x 18
Outdoor
Heat
Exchanger
Size (W x H x D) mm 661 x 504 x 18.19
715 x 588 x 18.19
Material PP-12X13H2 PP-12X13H2
Air Filter
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 10A 10A
Thermostat - -
Protection Device - -
COOLING HEATING COOLING HEATING
TEMPERATURE (°C )
DB WB DB WB DB WB DB WB
Maximum 32 23 30 - 32 23 30 -
Indoor Operation Range
Minimum 16 11 16 - 16 11 16 -
Maximum 43 26 24 18 43 26 24 18
Outdoor Operation Range
Minimum 16 11 -5 -6 16 11 -5 -6
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19°C Wet Bu lb (66.2°F
Wet Bulb) and outdoor air temperature of 35°C Dry B ulb (95.0°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bu lb).
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor ai r
temperature of 7°C Dry Bulb (44.6°F Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb).
3. Specifications are subjected to change without prior notice for further improvement.
