Panasonic CS-ME12CKPG Service Manual

4.1.2. Outdoor Unit
Model name CU-2E15CBPG CU-2E18CBPG CU-3E23CBPG CU-4E27CBPG
Indoor-units Combination 2.2 kW + 2.2 kW 3.2 kW + 3.2 kW 2.8 kW + 3.2 kW +
4.0 kW
3.2 kW + 3.2 kW +
3.2 kW + 4.0 kW
Power Source Single phase , 230 V, 50 Hz (Power supply from outdoor unit)
Cooling
Operation
Capacity kW 4.5 (1.5 - 5.0) 5.2 (1.5 - 5.4) 6.8 (2.8 - 8.4) 8.0 (3.0 - 9.2)
Electrical
Data
Running Current A 5.75 7.10 8.50 8.70
Power Input W 1 230 (250 - 1
350)
1 520 (250 - 1
580)
1 950 (490 - 2
800)
1 980 (530 - 2
870)
EER W/W 3.66 3.42 3.49 4.04
Noise Sound Pressure
Level
dB 47 49 48 48
Sound Power Level dB 62 64 61 61
Heating
Operation
Capacity kW 5.4 (1.1 - 7.0) 5.6 (1.1 - 7.2) 8.6 (3.5 - 9.1) 9.4 (4.2 - 10.6)
Electrical
Data
Running Current A 5.20 5.35 8.30 9.10
Power Input W 1 170 (210 - 1
670)
1 210 (210 - 1
700)
1 880 (560 - 2
710)
2 080 (700 - 3
060)
COP W/W 4.62 4.63 4.57 4.52
Noise Sound Pressure
Level
dB 49 51 49 49
Sound Power Level dB 64 66 62 62
Maximum Current A 12.0 12.0 18.5 19.0
Starting Current A 5.75 7.10 8.50 9.10
Circuit Breaker Capacity A 15 15 20 20
Dimensions Height mm 540 540 735 908
Width mm 780 (+70) 780 (+70) 826 (+110) 900
Depth mm 289 289 300 320
Net Weight kg 38 38 57 73
Connecting Cable 3 + 1 (earth) ø1.5 mm
2
Pipe Length Range (1 room) m 3-20 3-20 3-25 3-25
Maximum Pipe Length (Total room) m 30 30 50 70
Refrigerant
Pipe
Diameter
Liquid Side mm 6.35 6.35 6.35 6.35
Gas Side mm 9.52 9.52 9.52 9.52
Compressor Type Scroll Type Hermetically Sealed Swing Type
Motor Type DC Brushless(4-poles) DC Brushless(4-poles)
Rated Output W 1,200 1,500 1900 2200
Air
Circulation
Type Propeller Fan Propeller Fan
Motor Type DC Brushless(8-poles) DC Brushless(8-poles)
Rated Output W 40 53 51
Fan Speed Low rpm 690 700 680
High rpm 860 790 780
Heat
Exchanger
Type Plate fin configuration forced draft type
Tube Material Copper
Fin Material Aluminum
Row/Stage 2/20 2/32 2/40
FPI 16.5 18 19
Air Volume Low Cooling (Heating) m
3
/
min.
--- --- 45 (45) 42 (42)
High Cooling (Heating) m
3
/
min.
33.3(28.5) 34.5(31.0) 51 (47.6) 48.5 (45)
Refrigerant Control Device Expansion Valve Expansion Valve
Refrigerant Oil POE(RB-68A) FOC50K(Ethers)
Refrigerant (R410A) g 1,450 2,600 3,100
* Specifications are subject to change without notice for further improvement.
9
CS-ME7CKPG / CS-ME10CKPG / CS-ME12CKPG / CS-ME14CKPG / CS-ME18CKPG / CU-2E15CBPG / CU-2E18CBPG / CU-3E23CBPG / CU-4E27CBPG
