12.3. OUTDOOR UNIT (CU-3E23CBPG/CU-4E27CBPG)
Accessories supplied with the outdoor unit: CU-3E23CBPG
CU-4E27CBPG
Accessories supplied with the outdoor unit:
Cannot be installed hanging from ceiling or stacked.
Note
Outdoor Unit
1) Choose a place solid enough to bear the weight and vibration of the unit, where the operation noise will not be amplified.
2) Choose a location where the hot air discharged from the unit or the operation noise, will not cause a nuisance to the
neighbors of the user.
3) Avoid places near a bedroom and the like, so that the operation noise will cause no trouble.
4) There must be sufficient spaces for carrying the unit into and out of the site.
5) There must be sufficient space for air passage and no obstructions around the air inlet and the air outlet.
6) The site must be free from the possibility of flammable gas leakage in a nearby place. Locate the unit so that the noise
and the discharged hot air will not annoy the neighbors.
7) Install units, power cords and inter-unit cables at least 3 meter away from television and radio sets. This is to prevent
interference to images and sounds. (Noises may be heard even if they are more than 3 meter away depending on radio
wave conditions.)
8) In coastal areas or other places with salty atmosphere of sulfate gas, corrosion may shorten the life of the air
conditioner.
9) Since drain flows out of the outdoor unit, do not place under the unit anything which must be kept away from moisture.
Precautions for Selecting the Location
There is on the bottom packing case.
(For fixing electrical wire
anchor bands)
(For fixing electrical wire
anchor bands)
(A) Drain plug
There is on the bottom
packing case.
(B) Screw bag
(C) Installation Manual (D) Operation Manual
1
1
1
2
4
3
1
4
1
1
(A) Drain socket (B) Drain cap (C) Drain receiver
(E) Installation Manual (F) Operation Manual
(D) Screw bag
Accessories
73
CS-ME7CKPG / CS-ME10CKPG / CS-ME12CKPG / CS-ME14CKPG / CS-ME18CKPG / CU-2E15CBPG / CU-2E18CBPG / CU-3E23CBPG / CU-4E27CBPG
