Indoor Unit Indicator
Operation
(Green)
Timer
(Orange)
ON OFF FLASH
Run Stop
Hot start, deice control,
mode judging and ON-
Timer Operation detecting.
Timer set Timer not set
Malfunction happens.
Air Quality
(Green
Orange
Red )
The air quality can be detected automatically by the air quality sensor and shown
by the color of the air quality indicator as bellow..
Color of indocator :Green Air qualuty: Normal
Orange Poor
Red Bad
Indoor Fan Motor Control
1. Basic Fan Speed
Fan speed is determined by the setting of the remote control. And W5~W6 can be calculated
according the equations below:
Those operation modes W4:Low , W8 : Hi , W10 have been regulated in the EEPROM data.
Me- : W5=W4+W10
Me : W6=W5+W10
Me+ : W7=W6+W10
Cool.Dry
REMOTE
CONTROL
FAN SPEED
ROTATING
SPEED
SHI HI Me Me- Lo- Slo Sslo
W9C W8C Calculated W4C
W2C
W1C
REMOTE
CONTROL
FAN SPEED
ROTATING
SPEED
SHI
HI Me Me- Lo Lo- Slo Sslo
W8W W4W W3W
W2W
W1W
Heat
8.3 Common Features
W3C
Lo
Calculated
Me+
Me+
CS-PE9DKE / CU-PE9DKE / CS-PE12DKE / CU-PE12DKE
