Panasonic CS-PS36RKV

9
3. Location of Controls and Components
3.1 Indoor Unit
3.2 Outdoor Unit
3.3 Remote Control
Front Panel
Air Filters
Auto OFF/ON button
・Use when remote control is
misplaced
or a malfunction occurs
Remote Control Receiver
Maximum distances :8m
Alinium Fin
Vertical Airflow Direction Louver
・Do not adjust by hand.
Horizontal airflow direction louver
・Manually adjustable
Air flow direction
selection
OFF/ON
Temperature setting
Operation mode
Remote control
display
Fan speed
selection
Timer setting
Powerful/Quiet setting
Sleep setting
Auto DRY finish
setting
Check setting
Aluminum Fin
Front Panel
Air Filters
Auto OFF/ON button
・Use when remote control is
misplaced
or a malfunction occurs
Remote Control Receiver
Maximum distances :8m
Alinium Fin
Vertical Airflow Direction Louver
・Do not adjust by hand.
Horizontal airflow direction louver
・Manually adjustable
Dry
button
