Panasonic CS-PW12DKE

59
15 Replacement Parts List
Note:
1.All parts are supplied from GMAC, P.R. China.
2."*" marked parts are recommended to be kept in stock.
CS-PW9DKE
CS-PW12DKE
No. DESCRIPTION&NAME Q'ty CS-PW9DKE CS-PW12DKE RE
1 CHASSIS COMPLETE 1 CWD50C1427 CWD50C1427
2 FAN MOTOR 1 CWA921098 CWA921098
3 CROSS FLOW FAN COMPLETE 1 CWH02C1036 CWH02C1036
4 EVAPORATOR 1 CWB30C1738 CWB30C1738
5 FIXING BOARD 1 CWD661043 CWD661043
6 TUBE ASS'Y 1 CWT01C3507 CWT01C3507
7 PARTICULAR PIECE 1 CWD932454 CWD932454
8 DISCHARGE GRILLE COMPLETE 1 CWE20C2436 CWE20C2436
9 AIR SWING MOTOR 1 CWA981091 CWA981091
11 VERTICAL VANE(RIGHT) 1 CWE24C1104 CWE24C1104
12 VERTICAL VANE(LEFT) 1 CWE24C1105 CWE24C1105
13 HORIZONTAL VANE 1 CWE24C1100 CWE24C1100
14 C-BOX 1 CWH14C4713 CWH14C4720
15 CONTROL BOARD 1 CWH102265 CWH102265
16 PARTICULAR PIECE 1 CWD932493 CWD932493
17 POWER SUPPLY CORD COMPLETE 1 CWA20C2362 CWA20C2362
18 TERMINAL BOARD 1 CWA28C2086 CWA28C2086
19 MAIN PCB 1 CWA743748 CWA743749
20 INDICATOR COMPLETE 1 CWE39C1124 CWE39C1124
21 INDICATOR HOLDER-FRONT 1 CWD932491 CWD932491
22 INDICATOR HOLDER-BACK 1 CWD932492 CW D932492
23 INDICATOR PCB 1 CWA743836 CW A743836
24 SENSOR COMPLETE 1 CWA50C2271J CWA50C2271J
25 CONTROL BOARD FRONT COVER 1 CWH131235 CWH131235
26 CONTROL BOARD TOP COVER 1 CWH131237 CWH131237
27 REMOTE CONTROL 1 CWA75C2701 CWA75C2701
28 FRONT GRILLE COMPLETE 1 CWE11C3215 CWE11C3215
29 FRONT GRILLE 1 CWE22K1259 CWE22K1259
30 AIR FILTER 2 CWD001153 CWD001153
31 SCREW-FRONT GRILLE 2 XTT4+16CFJ XTT4+16CFJ
32 CAP-FRONT GRILLE 2 CWH521109 CWH521109
33 DRAIN HOSE 1 CWH851074 CWH851074
34 OPERATING INSTRUCTIONS 1 CWF564704 CWF564704
35 INSTALLATION INSTRUCTIONS 1 CWF612753 CWF612753
36 INSTALLATION INSTRUCTIONS 1 CWF612754 CWF612754
37 INSTALLATION INSTRUCTIONS 1 CWF612755 CWF612755
38 INSTALLATION PLATE 1 CWH361069 CWH361069
CS-PW9DKE / CU-PW9DKE / CS-PW12DKE / CU-PW12DKE
