Panasonic CS-S18KKQ Service Manual

5
2 Specification
Indoor CS-S9KKQ CS-S12KKQ
Model
Outdoor CU-S9KKQ CU-S12KKQ
Performance Test Condition JIS JIS
Phase, Hz Single, 60 Single, 60
Power Supply
V 220 230 220 230
Min. Mid. Max. Min. Mid. Max. Min. Mid. Max. Min. Mid. Max.
kW 0.80 2.65 3.20 0.80 2.65 3.20 0.85 3.23 4.00 0.85 3.23 4.00
BTU/h 2730 9040 10900 2730 9040 10900 2900 11000 13600 2900 11000 13600
Capacity
kJ/h 2880 9540 11520 2880 9540 11520 3060 11630 14400 3060 11630 14400
Running Current A - 3.4 - - 3.3 - - 4.1 - - 3.9 -
Input Power W 170 695 870 170 695 870 175 855 1.14k 175 855 1.14k
W/W 4.71 3.81 3.68 4.71 3.81 3.68 4.86 3.78 3.51 4.86 3.78 3.51
Btu/hW 16.06 13.01 12.53 16.06 13.01 12.53 16.57 12.87 11.93 16.57 12.87 11.93
EER
kJ/hW 16.9 13.7 13.2 16.9 13.7 13.2 17.5 13.6 12.6 17.5 13.6 12.6
Power Factor % - 93 - - 92 - - 95 - - 95 -
Indoor Noise (H / L / QLo) dB-A 36 / 26 / 23 36 / 26 / 23 38 / 28 / 25 38 / 28 / 25
Cooling
Outdoor Noise (H / L) dB-A 46 / - 47 / - 47 / - 48 / -
Max Current (A) / Max Input Power (W) 5.8 / 1.04k 7.2 / 1.35k
Starting Current (A) 3.4 4.1
Type Hermetic Motor Hermetic Motor
Motor Type Brushless (6 poles) Brushless (6 poles)
Compressor
Output Power W 650 650
Type Cross-flow fan Cross-flow fan
Material ASG20K1 ASG20K1
Motor Type Induction (4 poles) Induction (4 poles)
Input Power W 44 44
Output Power W 20 20
QLo rpm 680 - 680 680 - 680
Lo rpm 750 - 750 750 - 750
Me rpm 880 - 880 900 - 900
Hi rpm 1020 - 1020 1060 - 1060
Indoor Fan
Speed
SHi rpm 1130 - 1130 1130 - 1130
Type Propeller Propeller
Material PP PP
Motor Type Induction (6 poles) Induction (6 poles)
Input Power W 56 -60 65 - 78
Output Power W 20 28
Outdoor Fan
Speed Hi rpm 770 - 800 790 - 820
Moisture Removal L/h (Pt/h) 1.6 (3.4) 1.8 (3.8)
QLo m
3
/min (ft
3
/min) 6.4 (230) 6.7 (240)
Lo m
3
/min (ft
3
/min) 7.1 (250) 7.4 (260)
Me m
3
/min (ft
3
/min) 8.3 (290) 8.9 (315)
Hi m
3
/min (ft
3
/min) 9.6 (340) 10.5 (370)
Indoor Airflow
SHi m
3
/min (ft
3
/min) 10.6 (380) 11.2 (395)
Outdoor
Airflow
Hi m
3
/min (ft
3
/min) 22.0 (780) 22.9 (810) 31.2 (1100) 32.6 (1150)
