4
REMOTE CONTROL
5
TO ADJUST VERTICAL AIRFLOW DIRECTION
(5 OPTIONS)
AIR SWING
• Keeps the room ventilated.
• In COOL/DRY mode, if AUTO is set, the louver swing
up/down automatically.
6
TO ADJUST AIRFLOW DIRECTION (5 OPTIONS)
(PAGE 5)
AIR SWING
• Keeps the room ventilated.
• In COOL/DRY mode, if AUTO is set, the louver swing
left/right and up/down automatically.
7
TO MONITOR HUMAN PRESENCE
& ACTIVITY FOR ENERGY SAVING
ECO
PATROL
ECO 1 ECO 2 ECO OFF
+3°C
Heat Source & Movement
Low
High
+2°C
Set Temperature
None
-1°C
Set Fan Speed
≤ Medium
Fan
+1 tap
• — ECO 1 - To optimize comfort and energy saving.
• --- ECO 2 - To maximize energy saving.
Press the remote control’s button
1
TO TURN ON OR OFF THE UNIT
• Please be aware of the OFF indication on the remote
control display to prevent the unit from starting/stopping
improperly.
2
TO SET TEMPERATURE
• Selection range: 16˚C ~ 30˚C.
• Operating the unit within the recommended temperature
could induce energy saving.
COOL mode : 26˚C ~ 28˚C.
DRY mode : 1˚C ~ 2˚C lower than room temperature.
3
TO SELECT OPERATION MODE
AUTO mode - For your convenience
• During operation mode selection the power indicator
blinks.
• Unit selects operation mode during startup according to
temperature setting and room temperature.
COOL mode - To enjoy cool air
• Use curtains to screen off sunlight and outdoor heat to
reduce power consumption during cool mode.
DRY mode - To dehumidify the environment
• Unit operates at low fan speed to give a gentle cooling
operation.
4
TO SELECT FAN SPEED (5 OPTIONS)
FAN
PEED
• For AUTO, the indoor fan speed is automatically adjusted
according to the operation mode.
Maximum
distances: 8m
INDICATOR
PATROL SENSOR
(Red/Orange/Blue)
POWER
(Green)
TIMER
(Orange)
QUIET
(Orange)
POWERFUL
(Orange)
(Blue)
ECO PATROL
(Green)
S9KKQ, S12KKQ
4
5
2
11
3
10
12
13
15
Remote
Control display
14
7
9
1
8
To Next Page
