Panasonic CS-TZ60TKEW

127
21. Service Data
Service data provided are based on the air conditioner running under rated frequency during forced cooling / forced
heating mode.
21.1 Cool Mode Outdoor Air Temperature Characteristic
Condition
- Indoor room temperature: 27°C Dry Bulb/19°C Wet Bulb
- Unit setting: Standard piping length, forced cooling at 16°C, Hi fan
- Compressor frequency: Rated for cooling operation
- Piping length: 5m
- Voltage: 230V
21.1.1 CS-TZ60TKEW CU-TZ60TKE
Indoor Discharge
Air Temperature (°C)
Outdoor Air Temperature (°C)
Low Pressure (MPa)
Outdoor Air Temperature (°C)
Current (A)
Outdoor Air Temperature (°C)
4.00
5.00
6.00
7.00
8.00
9.00
10.00
11.00
13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45
13.0
14.0
15.0
16.0
13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45
0.85
0.95
1.05
13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45
