 Multi Split Combination Possibility:
o A single outdoor unit enables air conditioning of up to two separate rooms for CU-2Z35TBE, CU-2Z41TBE,
CU-2Z50TBE.
CONNECTABLE INDOOR UNIT
OUTDOOR UNIT
CU-2Z35TBE CU-2Z41TBE CU-2Z50TBE
ROOM A B A B A B
Wall
1.6kW
CS-MZ16TKE
● ● ● ● ● ●
CS-MTZ16TKE
2.0kW
CS-Z20TKEW
● ● ● ● ● ●
CS-XZ20TKEW
CS-TZ20TKEW
CS-TE20TKEW
2.5kW
CS-Z25TKEW
● ● ● ● ● ●
CS-XZ25TKEW
CS-TZ25TKEW
CS-TE25TKEW
CS-E9PD3EA
CS-E9PB4EA
3.5kW
CS-Z35TKEW
● – ● – ● ●
CS-XZ35TKEW
CS-TZ35TKEW
CS-TE35TKEW
CS-E12QD3EAW
CS-E12PB4EA
4.2kW
CS-Z42TKEW
● – ● – ● – CS-TZ42TKEW
CS-TE42TKEW
5.0kW
CS-Z50TKEW
● – ● – ● –
CS-XZ50TKEW
CS-TZ50TKEW
CS-TE50TKEW
CS-E18RD3EAW
CS-E18RB4EAW
Capacity range of connectable indoor units 3.2kW ~ 6.0kW 3.2kW ~ 6.0kW 3.2kW ~ 7.7kW
Pipe Length
1-room maximum pipe length (m) 20 20 20
Allowable elevation (m) 10 10 10
Total allowable pipe length (m) 30 30 30
Total pipe length for maximum
chargeless length (m)
20 20 20
Additional gas amount over
chargeless length (g/m)
15 15 15
Note*: Above outdoor unit is contains and operates with refrigerant R32 gas.
