21
Indoor
Model CS-Z60UD3RAW
POS (EAN) 5025232886944
Outdoor
Model CU-Z60UBRA
POS (EAN) 5025232886999
Indoor Fan
Type Sirocco
Material PP GFZ010A / GF20%
Motor Type DC / Transistor (8-poles)
Input Power W –
Output Power W 51
Speed
QLo
Cool rpm 920
Heat rpm 920
Lo
Cool rpm 980
Heat rpm 1000
Me
Cool rpm 1230
Heat rpm 1240
Hi
Cool rpm 1480
Heat rpm 1480
SHi
Cool rpm 1530
Heat rpm 1530
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type DC (8-poles)
Input Power W –
Output Power W 40
Speed Hi
Cool rpm 770
Heat rpm 720
Moisture Removal L/h (Pt/h) 3.1 (6.6)
Indoor
Airflow
QLo
Cool m
3
/min (ft
3
/min.) 8.9 (310)
Heat m
3
/min (ft
3
/min.) 8.7 (310)
Lo
Cool m
3
/min (ft
3
/min.) 9.4 (330)
Heat m
3
/min (ft
3
/min.) 9.7 (340)
Me
Cool m
3
/min (ft
3
/min.) 12.6 (445)
Heat m
3
/min (ft
3
/min.) 12.7 (450)
Hi
Cool m
3
/min (ft
3
/min.) (L/S) 15.7 (555) (262)
Heat m
3
/min (ft
3
/min.) (L/S) 15.7 (555) (262)
SHi
Cool m
3
/min (ft
3
/min.) 16.4 (580)
Heat m
3
/min (ft
3
/min.) 16.0 (565)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min.) 42.0 (1485)
Heat m
3
/min (ft
3
/min.) 39.2 (1385)
Refrigeration
Cycle
Control Device Expansion Valve
Refrigerant Oil cm
3
FW50S (450)
Refrigerant Type g (oz) R32, 1.17k (41.3)
Dimension
Unit
Height (I/D / O/D) mm (inch) 200 (7-7/8) / 695 (27-3/8)
Width (I/D / O/D) mm (inch) 750 (29-17/32) / 875 (34-15/32)
Depth (I/D / O/D) mm (inch) 640 (25-7/32) / 320 (12-5/8)
Pckg.
(Stacking
Condition)
Height (I/D / O/D) mm (inch) 211 (8-5/16) / 796 (31-11/32)
Width (I/D / O/D) mm (inch) 1043 (41-3/32) / 1049 (41-5/16)
Depth (I/D / O/D) mm (inch) 751 (29-19/32) / 460 (18-1/8)
Weight
Net (I/D / O/D) kg (lb) 19 (42) / 43 (93)
Gross (I/D / O/D) kg (lb) 24 (53) / 48 (104)
