Panasonic CS-Z35UD3RAW - Indoor Unit Dimensions and Filter Installation

48
Dimension of the indoor unit
640
692 (Flange for air outlet duct)
Flange for air outlet duct
564 (Suspension bolt pitch)
Suspension lug
824 (Suspension bolt pitch)
Water inlet
194
38
126
155
23
15
22
40
14
14
23
23
231231220
704
* Filter Uninstalled
10-ø3.1(Hole)
220
200
150
120
5-ø3.1(Hole)
640 (160x4)
29
96
66
26
750
37
33
81
30
30
238
44
143
80
10
84
2-ø3.1(Hole)
28
153
150
680
27
145
Inspection access
(450x450)
(Field supply)
14
In case of Bottom Intake
1 Remove the frame filter assy as shown in
diagram 1
2 Remove cover plate as shown in diagram 1
3 Fix frame filter assy as shown in diagram 2
4 Fix cover plate as shown in diagram 2 with
the dummy hole downward.
1
2
Dummy hole
Dummy hole
Air intake
Air intake
Frame
Filter
Assy
Air
discharge
Air discharge
Cover plate
Cover plate
Frame Filter
Assy
Fixing Frame Filter Assy
* Attach the frame fi lter assy to
the main unit while pushing the
tip of the latches in the direction
of the arrow.
In case of bottom side
Main unit
Filter Assy
In case of back side
